4.4.4 Menu Option - Start homing

This mode is used to home the stage.
Press the MENU button, then use the wheel to scroll
through the menu options.
Press the MENU button to enter the Start Homing option.
The display shows a decreasing position count while the
stage is homing.
Once homing is complete, the display shows the position
at 0.0000 mm and 'Homed' is displayed.
To stop the move, press the MENU button.

4.4.5 Menu Option - Velocity

This mode is used to move to set the max velocity.
Press the MENU button, then use the wheel to scroll
through the menu options.
Press the MENU button to enter the Velocity option.
Use the wheel to adjust the max velocity, e.g. 1.68 mm/s,
then press the MENU button to store the setting.
Subsequent moves will be performed at the velocity
entered.
Brushless DC Servo Driver K-Cube
