I N S T A L L A T I O N G U I D E
3 ) A S S E M B L Y : C O N C U R R E N C E C O N T .
F L A T H E A D
B O L T S
Once all the panhead bolts have been tightened the
table should look like Figure 4.
F I G U R E 4 : B O T H B E A M S I N S T A L L E D
The next step of installation is shown in Figure
5 with the flathead bolts passing through the
LZYPLATE and into the Bases.
Some adjustment of the LZYPLATE location might
be necessary.
F I G U R E 5 : T O P P L A T E F I N A L I N S T A L L A T I O N
Once the LZYPLATE have all been bolted into the
Bases the Top may be placed on the assembled Base.
Use the #10 screws provided to attach the Top to the
Base through the LZYPLATEs.
Depending on the width of the table the Top may be
in multiple pieces for shipping purposes. Tite-Joint
connectors are provided for attaching the Top pieces
to each other.
F I G U R E 6 : F I N I S H E D T A B L E
