Brakes; Brake Wear Inspection - Triumph Rocket 3 TFC 2020 Owner's Handbook Manual

• Fill the final drive unit with fully
synthetic 75W/90 hypoid oil that
meets specification API Service Level
GL5, such as Castrol SAF-XO fully
synthetic hypoid oil, until the level of
oil inside the final drive unit is level
with the bottom of the filler.
• Refit the filler level plug and tighten
to 25 Nm.

Brakes

Brake Wear Inspection

1
B00124
1. Brake pads
2. Minimum thickness line
Brake pads must
in accordance
requirements and replaced if worn to, or
beyond the minimum service thickness.
If the lining thickness of any pad (front
or rear brakes) is less than 1.5 mm
(0.06 in), that is, if the pad has worn
down to the bottom of the grooves,
replace all the pads on the wheel.
Maintenance
2
be inspected
with scheduled
129
