SEA FURY.
Instruction Manual.
Epoxy.
INSTALLINING THE VERTICAL STABILIZER.
C/A glue.
Hinge.
Hinge.
Remove covering.
Epoxy.
Put the vertical stabilizer into the in the top
of the horizontal fin. The bottom edge of the
stabilizer should also be firmly pushed against
the top of the horizontal stabilizer.
ELEVATOR - RUDDER PUSHROD
Vertical
INSTALLATION.
Stabilizer.
Horizontal
90º
Stabilizer.
Rudder control horn.
Epoxy.
Elevator control horn.
19
