WS-AP3825 LED Indicators

Both models of the WS-AP3825 have four LED indicators, shown in
LEDs provide status information, described in
AP3825. For more information, see the Extreme Networks Wireless Convergence Software
User Guide.
WS-AP3825 LEDs (Front, lower right)
Figure 4
1 AP status
2
LAN 1 (Ethernet 1) link state
3
LAN 2 (Ethernet 2) link state
Table 1 WS-AP3825 LED Indications
LED
1 (AP status)
Extreme Networks Wireless AP3825 Installation Guide
Table 1, on the current state of the WS-
4
Radio 2 status (2.4 GHz)
5
Radio 1 status (5 GHz)
Status Description
On Green Indicates the WS-AP3825 is working
normally.
Flashing Green Indicates:
running a self test
loading software program
On Amber Indicates a CPU/system failure.
