1: Component Replacement

Installing the Front Fan Assembly

44
Use the following procedure to install the front fan assembly (refer to Figure 1-18 on page 45):
Warning:
You must disconnect the workstation from site power (by disconnecting the AC
power cords from the power outlet) before you attempt to service any internal components.
Failure to maintain proper safety measures while accessing internal components can expose
you to dangerous power levels, resulting in injury or death.
1. Lower the fan assembly into the bottom of enclosure and push the top of the assembly into
place.
2. Tighten the two Phillips screws to hold the fan assembly in place at the top of the fan
assembly.
3. Place the front door in place and close the latch at the bottom of the door.
4. Plug the AC power cords into rear of the enclosure and into the power outlet.
5. Move the system enable switch on the rear of the enclosure to the ON position
6. Boot the operating system.
007-5650-001
