System Fan Assembly Replacement; Figure 1-15 Front And Rear Fan Assemblies - Silicon Graphics Octane III Component Replacement Manual

Deskside

Hide thumbs Also See for Octane III:

Table of Contents

System Fan Assembly Replacement

007-5650-001

Warning:

Only personnel with extensive experience repairing server hardware should

attempt to replace or upgrade components inside an SGI Octane III deskside workstation

enclosure.

Each enclosure has two sets of 6-fan assemblies to provide the main cooling for the system. One

fan assembly is located on the front of the enclosure (behind the front cover); the other fan

assembly is located on the rear of the enclosure.

Front Fan Assemblies

(with Front Cover

Removed)

Figure 1-15

Front and Rear Fan Assemblies

System Fan Assembly Replacement

Rear Fan Assemblies
