Manipulating The System Trays; Figure 1-1 System Trays - Silicon Graphics Octane III Component Replacement Manual

Deskside

Hide thumbs Also See for Octane III:

Table of Contents

Manipulating the System Trays

System Trays

(1-2)

007-5650-001

Warning:

Only personnel with extensive experience repairing server hardware should

attempt to replace or upgrade components inside an SGI Octane III deskside workstation

enclosure.

The system trays are accessed via the rear of the system enclosure; refer to Figure 1-1. You must

remove the rear fan assemblies to access the system trays. You will manipulate system trays to

replace/upgrade memory DIMMs, disk drives, and PCIe cards.

Figure 1-1

System Trays

Manipulating the System Trays
