PAR200B Audio Selector Panel, COM radio Controller and Intercom System
AUDIO PANEL POWER REQUIREMENTS (Including Internal Lighting):
Voltage:
Maximum Current:
Audio selector panel input impedance:
Input Isolation:
Receiver Inputs:
Unswitched Inputs:
Transmitter Selections:
Headphone Impedance:
Headphone Output:
Speaker Output (into 4 ) with no clipping
14 VDC:
28 VDC:
Microphone Impedance:
Intercom Positions:
Music Inputs:
Music Muting:
Distortion:
Mic Freq. Response, 3 dB:
Music Freq. Response, 3 dB:
Bluetooth FCC ID
Radio Type
Channels (Transmit & receive)
Frequency Selection
Frequency Display
Frequency control
Power consumption Receive (no signal)
Transmit
Input Voltage
Power output
Receiver sensitivity
Data Interface
Headset volume output
Temperature range
Stability
Dimensions
Weight
FCC ID:
200-228-0300
PS Engineering Inc. ®
Installation and Operator's Manual
11-33 VDC
2.5 Amp (Externally protected by a 3A pull-type
breaker)
Audio Selector Specifications
510 
-60 dB (min.)
4 (Com 1, Com 2, Nav 1, Nav 2)
4
3 (Com 1, Com 2,
Com1/2)
150 – 1000 
38 mW each headset, no clipping <1% THD typical
into 150
3 Watts (min.)
10 Watts (min.)
150 - 600 
Intercom Specifications
4 places (with individual IntelliVox® circuits) (8 with
expansion, -0202 ONLY)
2, (Independent, Stereo)
>-30 dB "Soft Mute" when Com or intercom active.
<1% THD @ 38 mW into 150
300 Hz - 6000 Hz
10 Hz – 16 kHz
Class 3, FCC ID QOQWT32I
TY91L VHF Transceiver Specifications
Amplitude Modulation (AM) Aircraft Transceiver
760 channels, 25KHz spacing
2280 channels, 8.33 kHz spacing
118.000 – 136.992MHz
On PAR200B Audio Panel
Alpha/numeric OLED display on PAR200B
PLL frequency synthesis, which is microprocessor
controlled in TY91.
2.8W @ 14VDC
3.2A
11-33 VDC 5A Circuit Breaker.
5 watts (nominal) VSWR Tolerance < 2:1 for best op-
eration (5:1 without damage)
-6dB SINAD @ 5µV (1KHz audio with 70% modula-
tion)
RS232
Nominal 100 milliwatts output to 600 Ω
-20 to +70 degrees Celsius
< +/- 4.00 ppm
W-2.5" x H-1.9" x D6.3" (plus 1.5" for harness) W-
66 mm xH-48mm D-160 (plus 35mm for harness)
0.77 lbs.
0.350 kg
VZI00882
