PAR200B Audio Selector Panel, COM radio Controller and Intercom System
circumstances, combine a microphone and headphone wiring into the same shielded bundle. Always use a 2-
or 3-conductor, shield wire as shown on the installation-wiring diagram.
The shields can be daisy-chained together, and then connected to the ground lugs mounted on the center of
the back plate.
Radiated signals can be a factor when low-level microphone signals are "bundled" with current carrying
power wires. Keep these cables physically separated. It is very important that you use insulated washers to
isolate the ground return path from the airframe to all headphone and microphone jacks.
2.4.1.1
Music Inputs and Noise
PAR200B units utilize differential music inputs to help prevent noise from entering the music system. This
feature is usually transparent to the installer; however, it is important that the appropriate music signal and
ground connections are made directly to the dedicated music signal and ground inputs on the PAR200B. The
power for In Flight Entertainment and audio panel should be a common bus.
If a music jack is installed for Music 1 or 2, we strongly recommend isolating the jack from airframe ground,
by using an insulated mounting plate.
Adding a high-performance audio control system, particularly in conjunction with high-performance active
noise canceling headsets, cannot improve on older avionics that were designed for cabin-speaker use. PS
Engineering makes no claim that the audio panel will provide a noise-free audio quality under all installation
conditions, particularly with older avionics.
2.4.2
Audio Panel Tray and Connector Assembly
The rack connectors mate with two 44-pin connectors in the PAR200B. The connectors are a sub-miniature
crimp-type, and require the use a hand crimp tool, from table below (or equiv.). The connectors are mounted
to the tray back plate with #4-40 screws (475-440-1038), from the inside of the tray and the mounting block,
431-891-0100. Ensure that proper strain relief and chafing precautions are made during wiring and installa-
tion, using the cable clamp (625-001-0002).
Manufacturer
AMP
Daniels
ITT-Cannon
Table 2-1 PAR200B Connector Pin crimping tools
Manufacturer
Mil-Spec
Daniels
Table 2-2 TY91 Connector Crimping tools
2.4.3
Audio Panel interface
The PAR200B is designed to interface with standard aircraft avionics, and presents a 500 receiver imped-
ance. For best results, a twisted-shielded cable is recommended from the avionics audio source to the audio
panel, with the shield grounded at the audio panel end.
Inputs N1 and N2 can be used to control navigation receiver audio, J1 Pins 17 WRT 18 and J1 19 WRT 20,
respectively.
Some avionics do not provide a separate audio low, and may introduce additional electrical noise into the
system. For best results, connect the audio low from the audio panel to the radio ground, using one conductor
of the twisted-shielded cable.
200-228-0300
PS Engineering Inc. ®
Installation and Operator's Manual
NOTE
Crimping Tool
601966-1
AFM8
995-0001-584
Crimping Tool
M22520/2-01
AFM8
Page 2-3
Positioner
601966-6
K42
995-0001-739
Positioner
M22520/2-08
K13-2
Extraction tool
91067-1
M24308-1
91067-1
Extraction tool
M24308-1
October 2019
