Including Trig Avionics TY91 (L)
Audio Selector Panel with VHF Communications Transceiver and
Patented under one or more of the following;
No. 4,941,187; 5,903,227; 6,160,496, and 6,493,450
FAA-TSO C139, TSO C169a (PARTIAL)
EASA ETSO C139, 2C169A (PARTIAL)
The product warranty is not valid unless this product is installed by an
Authorized PS Engineering dealer or is a direct replacement for a compatible
Any reproduction or retransmittal of this publication, or any portion thereof, without the expressed written permission of PS En-
gineering, Inc. is strictly prohibited. For further information, contact the Publications Manager at PS Engineering, Inc., 9800
Martel Road, Lenoir City, TN 37772. Phone (865) 988-9800, email contact@ps-engineering.com.
9800 Martel Road
Lenoir City, TN 37772
www.ps-engineering.com
PAR200B
With IntelliAudio®
Document P/N 200-228-0300
October 2019
High-fidelity Stereo Intercom
System Installation and Operation Manual
audio panel.
PS Engineering, Inc. 2019 ©
Copyright Notice
