PARTS AND HARDWARE
NEEDED FOR STEP 1
M8 – 1.25 X 12MM
Button socket head
cap screw (qty 8)
M6 - 1.0 x 30mm
Socket head cap screw
(qty 12)
Rail Components
Socket Bushing
(qty 12)
Right Hand Column
Top Supports
Left Hand Column
2
