STEP 5: CONNECT FRAME TO
BASE
10-24 X 2" SOCKET
UZWNUTA
HEAD CAP SCREW
(qty 4 per frame)
(qty 4 per frame)
Align to center set of holes
in frame when attaching
10-24 X 2" SOCKET
UZWNUTA
HEAD CAP SCREW
8
