- Page 1 Grid XTB with ULL bases (Shipped through March, 2015) Installation Instructions Rev 0715...
-
Page 2: Installation
2 - PACK 4 - PACK 6 - PACK 8 - PACK GRID XTB Installation... - Page 3 STEP 1: TAPE TOOLS NEEDED & PARTS PENCIL MEASURE 1/2” & 7/16” TORX SCREWDRIVER USLEG19H BITS UMCP48 FOR 60” GRID POWER INFEED UMCP60 FOR 72” GRID SOCKET WRENCH WITH ½” & 7/16” SOCKET 2-PACK QTY: 2 PHILLIPS 4-PACK QTY: 4 2-PACK QTY: 1 SCREWDRIVER 6-PACK QTY: 6...
- Page 4 STEP 2 HARDWARE IDENTIFICATION #10-24 x 3/8” #8-32 x ¼ TORX PHILLIPS PAN HEAD, PAN HEAD #10-24 x 2” UZSCREW W #10-24 NUT, WOOD SCREW 2-PACK QTY: 12 PHILLIPS PAN 2-PACK QTY: 8 UZNUTA SCREW1 4-PACK QTY: 24 HEAD, UZBOLTU 4-PACK QTY: 16 2-PACK QTY: 14 2-PACK QTY: 12...
- Page 5 STEP 3 ASSEMBLE ADJUSTABLE TABLE SEE END OF DOCUMENT FOR “CRANK” STYLE ASSEMBLIES FOR 72” LONG GRID TABLES FOR 60” LONG GRID TABLES...
- Page 6 STEP 4 IF ULRISER2 OR ULRISER3 PRE-ASSEMBLE PACKAGE WAS PURCHASED DO NOT USE ULF.GMTBRKT OR ULF.GMTBRKT29 NOTE ORIENTATION OF TIGHTEN CONNECTION ULF.GMTBRKT OR ULF.GMTBRKT29 ASSEMBLE ALL ULF.GMTBRKT’s OR ULF.GMTBRKT29 (RISER) TO ULF.WTC’s BEFORE MOVING FORWARD...
- Page 7 STEP 5 ASSEMBLING TABLE HOLD FIRMLY ON BOTH SIDES OF COLUMN AS YOU BEND TAB OVER BEND SLOTTED TAB OVER INSERT FASTENERS...
- Page 8 STEP 5 CONT. ALL ULF.WTC SHOULD BE SET TO .32 OR 5/16” FROM THE TOP OF PLASTIC LEG INSERT. TIGHTEN NUTS. DO NOT OVER TIGHTEN NUTS. THIS CAN CAUSE LEG COLUMN DEFORMATION AND INOPERATION OF TABLE. 5.7 END RUN ATTACH OTHER TABLE BASE TO ULF.WTC, TIGHTEN NUTS...
- Page 9 STEP 5 CONT. TERMINOLOGY 2 PACK 6 PACK 2 PACK 4 PACK 8 PACK...
- Page 10 STEP 5 CONT. 5.8 END RUN CONFIGURATION NOTE GRID XT 2 PACK ULF.WTC BOTH FACE INWARD FOR GRID XT 4 – 6 – 8 PACKS THIS AN END OF RUN CONFIGURATION FOLLOW STEPS 5.1 THRU 5.3 FOR DETAILED INSTRUCTIONS. NOTE THAT BOTH ULF.WTC CROSS BARS FACE THE SAME DIRECTION 5.9 MID RUN CONFIGURATION FOR GRID XT 4 –...
- Page 11 STEP 6 ATTACHING GRID VIEW OF ATTACHMENT WITH RISER ATTACH GRID TO ASSEMBLY USE MIDDLE HOLE AS SHOWN FOR ATTACHMENT NOTE: IF NOT ALL HOLES ARE ALIGNING, LOOSEN TELESCOPING LEG CONNECTOR (PAGE 4) ADJUST WIDTH AND TIGHTEN CONNECTIONS...
-
Page 12: Connecting Stations
STEP 7 CONNECTING STATIONS USE QTY: 4 5/16-18 FLANGE NUT 5/16-18 x 1” FLANGE BOLT TO CONNECT ULF.STRETCHER TO TABLE BASES AND TIGHTEN CONNECTIONS NOTE THAT STRETCHER FLANGES FACE INWARD ATTACH STRETCHERS TO ADJACENT TABLE(s) - Page 13 STEP 8 POWER ROUTES VIA GREEN ARROWS AND CONNECTING POWER CONNECTS TO LAY IN GRID POWER JUMPERS INSERT USLEG19H USE QTY 2 EA UZBOLTU & UZNUTA TO ATTACH LEG TO GRID PLACE USLEGAL19H (POWER INFEED) CABLE MANAGER NEAR FLOOR OUTLET. -NOTE THAT USLEGAL15 CAN BE PLACED ANYWHERE ALONG A GRID XT 4 –...
- Page 14 STEP 9 ATTACHING CABLE TROUGH...
- Page 15 STEP 10 ATTACHING WORK SURFACE...
- Page 16 STEP 11 ATTACHING TABLE CONTROLLERS...
- Page 17 “CRANK” TABLE BASE INSTRUCTIONS...
- Page 18 “CRANK” TABLE BASE INSTRUCTIONS CONT.
- Page 19 “CRANK” TABLE BASE INSTRUCTIONS CONT.
- Page 20 “CRANK” TABLE BASE INSTRUCTIONS CONT.
- Page 21 “CRANK” TABLE BASE INSTRUCTIONS CONT.
- Page 22 “CRANK” TABLE BASE CONFIGURATIONS 2-BAR OPTIONS...
- Page 23 “CRANK” TABLE BASE 3-BAR OPTIONS CONFIGURATIONS...
