ScrapBox WorkBox 3.0 Assembly Manual page 8

LEFT BOX
9
To secure door,
insert 8 Cams
along both sides of the
interior of the box and
turn with Allen Wrench until
locked in place.
10
Insert Shelf Pegs in
holes on Side 2.
We recommend placing
pegs as shown.
*Use rubber mallet to gently
tap into peg hole. Be sure
peg is secure.
15
11
7
3
8
x8
Locking
Cams
x24
Shelf Pegs
43
39
35
31
27
23
19
47
43
47
Left Box
Divider
Facing Side 2
11
Insert Shelf Pegs in
holes on Side 1 of Left Box Divider
to match peg placement from
step 10. *Gently tap with rubber mallet
until secure .
39
35
31
27
23
19
15
x24
Shelf Pegs
11
7
3
