ScrapBox WorkBox 3.0 Assembly Manual page 31

CENTER BOX
With TWO PEOPLE carefully lift the Center Box and place against wall.
Lift and attach Left and Right Box one at a time.
**CAUTION: Move slowly! Center box is very heavy!
32
Use (15) 13mm Euro Screws
per side to attach Left Box and
Right Box to Center Box hinges.
33
x1
1" Screw
(or x2 for Ergo White)
x1
Door Knob
(or x1 door handle
for Ergo White)
Use (2) 1"Screws to attach both
door handles.
OPTIONAL: If you did not purchase a crown, install sash lock on left and right box
using (4) 14mm Self-tapping screws.
x30
13mm
Euro Screws
LEFT BOX
for attaching ScrapBox Security Kit
included in your hardware
CENTER BOX
RIGHT BOX
It is SAFE to use
an Electric Screw Driver
to intall hinges.
31
