AMP Research Power Step Installation Manual

Chevrolet silverado1500 / gmc sierra 1500 - double cab/ chevrolet silverado1500 / gmc sierra 1500- crew cab 2014-18, chevrolet silverado hd / gmc sierra hd - double cab / chevrolet silverado hd / gmc sierra hd- crew cab 2015-19
Hide thumbs Also See for Power Step:

Advertisement

Quick Links

Download this manual
APPLICATION
Chevrolet Silverado1500 / GMC Sierra 1500 - Double Cab
Chevrolet Silverado1500 / GMC Sierra 1500- Crew Cab
Chevrolet Silverado HD / GMC Sierra HD - Double Cab
Chevrolet Silverado HD / GMC Sierra HD- Crew Cab
* Modification required to running board assembly. See Item 1 on page 3.
AMP RESEARCH TECH SUPPORT 1-888-983-2204 (Press 2) Monday - Friday, 7:00 AM - 5:00 PM PST
Invented, engineered and manufactured exclusively by AMP Research in the USA. May be covered by one of the following patents:
6,641,158; 6,830,257; 6,834,875; 6,938,909; 7,055,839; 7,380,807; 7,398,985; 7,584,975 ©2012 AMP Research. All rights reserved.
Printed in USA.
I N S T A L L A T I O N G U I D E
1/12
*
2014-18
2014-18
*
2015-19
(excludes diesel engine)
2015-19
(excludes diesel engine)
INSTALLATION TIME
Professional installation recommended
1 2 3
TOOLS REQUIRED
q Safety goggles
q Measuring tape
q Flat blade screwdriver
q Power Drill
q 9/32" drill bit
q 13 mm socket
q 10 mm socket
q 7 mm socket
q Ratchet wrench and extension
q 13mm end wrench
q Wire crimpers
q Wire stripper / cutter
q
3 /16" hex key wrench (allen wrench)
q
5 mm hex key wrench (allen wrench)
q
4mm hex key wrench ( allen wrench )
q
Electrical tape
q
Weather proof caulking (silicone sealer)
q
Silicone spray
5-Year Limited Warranty
AMP Part #
75154-01A-B
75154-01A-B
75154-01A-B
75154-01A-B
3-5 Hours
SKILL LEVEL
4
4= Experienced
WARRANTY
IM75154 rev 10.06.20
www.4x4ok.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the Power Step and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AMP Research Power Step

Summary of Contents for AMP Research Power Step

  • Page 1 AMP RESEARCH TECH SUPPORT 1-888-983-2204 (Press 2) Monday - Friday, 7:00 AM - 5:00 PM PST Invented, engineered and manufactured exclusively by AMP Research in the USA. May be covered by one of the following patents: 6,641,158; 6,830,257; 6,834,875; 6,938,909; 7,055,839; 7,380,807; 7,398,985; 7,584,975 ©2012 AMP Research. All rights reserved.

  • Page 2: Exploded View

    A M P R E S E A R C H P O W E R S T E P – C H E V R O L E T / G M C INSTALLATION GUIDE Attaching motor to Linkage assembly The motors must be attached to the Linkage assemblies before continuing the installation process.
  • Page 3 A M P R E S E A R C H P O W E R S T E P – C H E V R O L E T / G M C Note: Some Applications require modification. Application Cut Length Crew Cab 79”...
  • Page 4 A M P R E S E A R C H P O W E R S T E P – C H E V R O L E T / G M C Hex Bolt with Conical Nut with Conical Hex Bolt with Conical U-nut Washer...
  • Page 5 A M P R E S E A R C H P O W E R S T E P – C H E V R O L E T / G M C 1500 MODELS ONLY! Front Idler Linkage: Thread supplied bolt (10) in about half way into the first sheetmetal tab / hole from Install U Nut (13) into position just forward of front.
  • Page 6 A M P R E S E A R C H P O W E R S T E P – C H E V R O L E T / G M C Route long end of wire harness above engine and Pull up front door sill plate covers as shown.
  • Page 7 A M P R E S E A R C H P O W E R S T E P – C H E V R O L E T / G M C Using a 7mm socket remove the 6 screws that secure Pry all panel fasteners loose.
  • Page 8 A M P R E S E A R C H P O W E R S T E P – C H E V R O L E T / G M C Route trigger wire into the door. Poke hole through Tape red wire to (grey with black wire on driver side and tan with white stripe on passenger side).
  • Page 9 A M P R E S E A R C H P O W E R S T E P – C H E V R O L E T / G M C Re-attach window seal. Ensure seal is pushed Replace plug and door latch cable.
  • Page 10 A M P R E S E A R C H P O W E R S T E P – C H E V R O L E T / G M C Use supplied red wire and feed through accordian Feed wire to front sill area.
  • Page 11 A M P R E S E A R C H P O W E R S T E P – C H E V R O L E T / G M C Remove door latch cable from door panel. Route trigger wire into the door.
  • Page 12 A M P R E S E A R C H P O W E R S T E P – C H E V R O L E T / G M C Reinstall fuse. Check that all doors activate the Power Step and the LED Lights work when doors open and close. Reinstall any remaining trim panels.
  • Page 13 The material that your product is made from can be recycled. Please also consider recycling the packaging that your product came in. www.4x4ok.com...
