Digi ConnectCore Wi-9P 9215 Hardware Reference Manual page 91

C h a p t e r 2
X30, U.FL connector
with decoupled connection
to X29 for secondary
(AUX)/GPS antenna
Dual SIM socket
If you have not done so already, insert your SIM card(s) as shown (GSM/GPRS networks
SIM
only):
Installation
Note:
ConnectCore 9P 9215, Wi-9P 9215 and 3G 9P 9215 Hardware Reference
91
ConnectCore 3G 9P 9215 Module
X29, U.FL connector
with 3.3V for
a
Insert primary SIM into
the lower SIM slot
SIM slots
The correct orientation for the SIMs is notched-side out, SIM cards are not
included in your Digi JumpStart Kit
active GPS
antenna
P1, PCIe connector
for the cellular module
Insert secondary SIM
b
card (if applicable)
®
.
J2, SMA to U.FL
adapter (U.FL
connector is on
the back side of
the SMA connector)
for primary antenna
connection
