A

Note:

Note:

Note:
WWAN
Note:
Interface
2G/3G cellular connectivity based on Qualcomm Gobi 3000:
www.digiembedded.com
Available Transmit Power Settings
(Maximum power setting will vary according to individual country regulations).
± )
Typical ( 2 dBm 25°C
802.11b/g:
– 14 dBm (~25 mW) @ 1, 2, 5.5, and 11 Mbps
12 dBm (~16 mW) @ 6,12, 18, 24, 36, 48, and 54 Mbps
–
6 dBm (~4 mW) @ 6,12, 18, 24, 36, 48, and 54 Mbps
–
802.11a:
– 6 dBm for all channels
During manufacturing, EVM values are verified up to -23 dBm rms for band A.
Available Transmit Power Settings (Typical (
Maximum power setting will vary according to individual country regulations.
Connector: 2 x U.FL
Please use the HIROSE U.FL-LP-N-2 extraction tool for removing a U.FL cable
from the ConnectCore Wi-9P 9215 or ConnectCore 3G 9P 9215 modules.
This WWAN Interface information applies to the ConnectCore 3G 9P 9215
module only.
Technology
1xEV-DO Rev A
1xRTT Rev 0
UMTS/HSDPA/HSUPA
±
2 dBm
Bands
BC0 - 800 MHz - US cell
BC1 - 1900MHz - US PCS
BC4 - 1800 MHz - KPCS
BC6 - 2100 MHz - IMT
B9 - 1700 MHz - Japan 1700 MHz
B8 - 900 MHz
B6 - 900 MHz - Japan 800 MHz
B4 - 1700/2100 - AWS
B5 - 850 MHz - US Cell
B3 - 1800 MHz - KPCS
B2 - 1900 MHz - US PCS
)
@ 25°C)
