www.digiembedded.com
X1 pin
Type
Module Functionality
number
46
O
BA8
47
O
BA9
48
O
BA10
49
O
BA11
50
O
BA12
51
O
BA13
52
O
BA14
53
O
BA15
54
O
BA16
55
O
GND
56
O
EXT_OE#
57
O
EXT_WE#
58
O
EXT_CSO#
59
O
EXT_CS2#
60
O
BE2#
61
O
BE3#
62
I
EXT_WAIT#
63
O
EXT_CLK#
64
P
GND
65
I
ETH_TPIN
66
O
ETH_ACTIVITY#
67
I
ETH_TPIP
68
O
ETH_LINK#
69
O
ETH_TPON
70
O
ETH_TPOP
71
P
GND
72
P
USB_VBUS
73
I
USB_OC#
74
I/O
USB_P
75
I/O
USB_N
76
O
USB_PWR#
77
I
Reserved
Comments
NS9215 BE2#
NS9215 BE3#
10k pull-up on module
Connected over a 22R resistor to NS9215
CLK_OUT1 pin
Low active signal with 330R resistor on module
Low active signal with 330R resistor on module
Power / See Note 1
See Note 1
See Note 1
See Note 1
See Note 1
16
