1.3 Overview

No. Name
1 Default
2 LAN / PoE
3 Microphone
DC 12V Terminal
4
Block
LED Indicator
Status LED
Power LED
1
2
Figure 1-1
Description
Resets the camera to factory default. For
details, see 1.6 Loading Factory Default.
Connects to a 10/100 Ethernet or PoE.
Records sounds.
Connects to power.
Description
The status LED turns on (green) when the
system is ready for use.
The power LED turns on (green) when
power is supplied to the camera.
1
Target Box Camera
3
4
3
