Configure LTU and NTU Interfaces

Select and configure the LTU- and NTU-related operating parameters as follows:
1 Type one of the following at the Config drop-down menu to display the Config LTU or NTU Interface menu:
• L for the Config LTU Interface menu
•
N for the Config NTU Interface menu
The Data Rate/# of TSs and Beginning TS parameters in the Config LTU and NTU Interface
are read-only displays.
menus
Settings menu as the "HDSL Payload Rate" (See
value is 0 with 32 time slots selected (unstructured mode) and 1 when less than 32 time slots
are selected (structured mode).
UTU-701 and ETU-751 List 1
(Figure 22).
(Figure 23).
Figure 22. Config LTU Interface Menu
Figure 23. Config NTU Interface Menu
The Data Rate/# of TSs value is set in the Config System
August 9, 2002
Figure 21 on page 37). The Beginning TS
