Overview
W DSL P
ORLD RODUCT
The line and desktop units are compatible with the WorldDSL products listed in
Model
UTU-702C
UTU-712C
UTU-722C
ETU-752C
ETU-762C
ETU-772C
EMS-830 List 1
EMS-830 List 2
(c)
ERE-811
ECA-800
ECA-801
ECA-802
ECA-804
ECA-807
(a) The EMS-830 List 1 supports protection switching, the EMS-830 List 2 does not.
(b) The EMS-830 List 2 is CE marked. The EMS-830 List 1 is not, and is intended for use in applications
where the CE Mark is not required.
(c) The UTU-701C is CE Marked in the ERE-811 List 5 remote enclosure only.
(d) The ECA-80x series of connector adapters and their pinouts are listed in
beginning on
8
C
OMPATIBILITY
Table 6. WorldDSL Product Compatibility
Description
Rate-Selectable HDSL Units
Rate-selectable HDSL Line Unit, Nx64k Serial Data Interface,
128 to 2048 kbps HDSL Line Rate
Rate-selectable HDSL Line Unit, Nx64k Serial Data Interface,
128 to 768 kbps HDSL Line Rate
Rate-selectable HDSL Line Unit, Nx64k Serial Data Interface,
128 to 256 kbps HDSL Line Rate
Rate-selectable HDSL Desktop Unit, Nx64k Serial Data Interface,
128 to 2048 kbps HDSL Line Rate
Rate-selectable HDSL Desktop Unit, Nx64k Serial Data Interface,
128 to 768 kbps HDSL Line Rate
Rate-selectable HDSL Desktop Unit, Nx64k Serial Data Interface,
128 to 256 kbps HDSL Line Rate
Shelves and Enclosures for UTU-701C
(a)
Exchange office management shelf, rear connector access
(b)
Exchange office management shelf, rear connector access
Single-slot remote enclosure with internal AC power supply
Connector Adapters for ETU-751C
D25M to M34F connector adapter (V.35)
D25M to D15F connector adapter (X.21)
DB9M to RJ-45 connector adapter (HDSL)
DB9M to 4-position terminal block connector (HDSL)
DB25M to DB37F connector adapter (RS-449)
page 65.
(d)
Table 36
August 9, 2002
700-701-100-02
Table 6.
Part Number
150-1422-02C
150-1422-12C
150-1422-22C
150-1432-02C
150-1432-12C
150-1432-22C
150-1400-01
150-1400-11
150-1411-1x
150-1470-01
150-1471-01
150-1472-01
150-1474-01
150-1477-01
through Table 39,
UTU-701 and ETU-751 List 1
