Basic Functions

Motion Control – General
The door opens motor-driven in accordance with the adjusted speed against the installed
spring. Ahead of the open position, the motor torque is reduced and the door is braked
down by the spring. The door is held in the open position by a reduced motor torque. The
closing action is performed through spring force only. Thereby, the motor adjusts the
speed. At the completion of the closing motion, deceleration occurs with adjustable
homing in speed over an adjustable angle (see section 7.4.2). The motor is switched off
when the door is closed.
Functionality of the unit
Opens the door in operating mode AUTO and in operating mode OFF in accordance
with "Teach-In General".
Opens the door in operating mode AUTO in accordance with "Teach-In General", or with
"Teach-In Key Switch" if this was performed after "Teach-In General".
This prevents the door from opening. It stops the door during opening.
If both, the safety device in opening direction and the safety device in closing
direction, respond at the same time during a motion, the door stops in place. Through
"Teach-In General", the safety sensor is disabled automatically over a predetermined
door swing range. If this function is not used, a jumper is inserted between 14–15.
Standard function:
Safety device in closing direction (safety sensor riding along in closing direction).
The door remains open. A commenced closing motion is reversed.
If both, the safety device in opening direction and the safety device in closing
direction, respond at the same time during a motion, the door stops in place.
Optional functions:
Safety device for the swing area
The door remains open or closed. A commenced motion is completed.
The safety device in opening direction has a higher priority than the safety device for
the swing area.
Safety Device Bodyguard
This function is only in use with the safety device "Bodyguard" of BEA.
The door remains open or closed. A commenced motion is completed. The safety
device in opening direction has a higher priority than the safety device "Bodyguard".
Using this function automatically changes the settings of Feedback Door State to "door
opening or door open". This feature is compulsory for the function "Bodyguard"
(See Feedback Door State)
If these safety functions are not used, a jumper is inserted between 18–19.
Output for active testing of the safety device in opening direction and safety device
in closing direction (e.g. for Eye-Tech of BEA).
An opening can only be initiated through the key switch.
An opening can be initiated by an activator, a key switch and also by "Push and Go"
depending upon configuration.
