Requirements for Installa-
tion Personnel
Fundamental Safety Meas-
ures – Appropriate Behav-
iour
Automatic Swing Doors
Door leaves may not open directly into areas in which other transit traffic takes place. If
door leaves open into an area in which there might be people, safety precaution are to
be taken if this is judged as necessary by the risk evaluation.
Danger points in the range of the opening motion are considered as safeguarded if:
– There is an adequate safety separation regarding the endangered parts of the human
body between the secondary closing edge and adjacent parts of the environment,
or
– The forces of the door leaves are limited to safe values,
or
– Monitored protective facilities will be installed between the secondary closing edge and
adjacent parts of the environment,
or
– The area of the secondary closing edge is protected with separating protective
facilities.
Danger positions during the closing motion are secured – depending on application – if
– The motion travel of a door leaf is continuously supervised through (error-proof and
monitored) presence sensors,
or
– Monitored protective facilities are installed at the main and/or secondary closing edge,
or
– The motion travel of a door leaf is secured with switching mats.
The leaves must be manufactured from materials that will not lead to a potential danger
of injury when breaking (e.g. toughened safety glass, compound safety glass etc. when
using glass).
2.3

Organizational Measures

The installation on site may be carried out only by qualified personnel who have sufficient
knowledge in the area of the power-operated doors due to vocational training and
experience and are acquainted with the relevant national workers protection rules,
accident prevention regulations, directives and generally recognized rules of the
technology to such an extent that they can judge the safe-for-working status of power-
operated doors.
Experience/vocational training in metal construction and in fastening techniques is a
requirement.
If necessary, qualified employees of the contract partner can make use of the training
offered by TORMAX (training courses).
Depending upon leaf weight, an assistant must be available for the installation.
• Use the system only in a technically sound state. Eliminate faults immediately that may
impair safety.
• Keep fingers away from any mobile parts. Special caution is required in the area of the
drive lever, the linkage and the secondary closing edges of the hinges.
!
• Use exclusively tools that are suitable for the respective work procedure. Pay attention
to good condition of the tools.
• Electric voltage/current: The operator is to be disconnected from electrical mains
before any work is performed on electrical parts.
Install cabling only after the installation is complete.
Plug in the power plug only after all internal cables are connected.
Installation On Site SWINGDOOR Smart Drive 1101 T-1132 e
7
