Summary of Contents for Tormax Automatic 2101
- Page 1 T-1672 e 8.4.21 Translation of the original instructions for use Instructions for Use For Automatic Sliding Doors with Drive: TORMAX 2101 Sliding Door Drive Safety instructions in chapter 2 must be observed!
-
Page 2: Table Of Contents
System with Operating Mode Switch Maintenance Cleaning Functional Checks Maintenance and Testing Appendix Fault Table Check-list for Functional Checks First edition: 4.13, Update: 9.13, 4.14, 5.15, 4.21 We reserve the right to make technical changes. Instructions for Use TORMAX 2101 T-1672 e... -
Page 3: General Information
1.3 Area of Application Product name, door system: Automatic sliding door TORMAX 2101 Sliding Door Drive Product name, door drive: Identification plate: The identification plate with the serial number is attached to the header section. Instructions for Use TORMAX 2101 T-1672 e... -
Page 4: Explanation Of The Symbols
Optional components which are not present in all systems. 1.5 Technical Data Drive type: Electro-mechanical sliding door drive with DC motor Control system: Control unit 2101 Control unit 2101 MCU42-COU-A MCU42-COU-B Mains connection: 230 / 115 V AC 230 V AC Nominal voltage max.:... -
Page 5: Safety
2.4 Hazards and Risks Depending on the system design and equipment, there is a residual risk of crushing, entanglement and collision in the movement area of the door leaves – albeit with restricted force. Instructions for Use TORMAX 2101 T-1672 e... -
Page 6: Checks
• Disconnect the system from the power supply. • Open the door manually and leave open if it is installed in an escape route. See section 5 for rectification of faults. Instructions for Use TORMAX 2101 T-1672 e... -
Page 7: Disposal
2.7 Disposal This system must be properly dismantled at the end of its working life. Its disposal must comply with national regulations. We recommend that you contact a skilled person disposal company. Warning Aggressive acids Risk of injury if you dismantle the battery module. •... -
Page 8: Product Description
£ Presence sensor: main closing edge protection b) £ Presence sensor, external: main closing edge protection c) £ Safety beams Emergency systems a) £ Power switch / fuse b) £ Emergency on/off switch £ Depending on the system’s equipment Instructions for Use TORMAX 2101 T-1672 e... -
Page 9: System Function
The system can be locked in operating mode OFF by means of an electro-mechanical lock u. In the event of a power failure the locks can also be directly activated by the optional manual facility. Instructions for Use TORMAX 2101 T-1672 e... -
Page 10: Operating Modes
Operating mode EXIT is normally used for the period before the shop or office closes. The door will only open automatically when activated by the internal sensor. When the door opens the external sensor is also monitored for safety reasons. Instructions for Use TORMAX 2101 T-1672 e... - Page 11 The door leaves can be freely moved. This operating mode can be used for cleaning the door leaves and the floor guide or for temporarily shutting down the door. The system is reset after leaving this operating mode. Instructions for Use TORMAX 2101 T-1672 e...
-
Page 12: Operation
Fault indication e.g. LED 4 flashes. See Section 5 for how to proceed in the event of faults and how to reset the system. See chapter 7 for the definition of the fault. Instructions for Use TORMAX 2101 T-1672 e... -
Page 13: Operation With An Operating Mode Switch
The battery remains switched on in AUTO, AUTORED, EXIT and OPEN until the battery charge is too low. The door opens before switching off. The battery switches off in OFF as soon as the door is closed for at least 10 s (and locked where appropriate). Instructions for Use TORMAX 2101 T-1672 e... -
Page 14: Procedure In The Event Of A Fault
TORMAX dealer. In this case note the fault number and inform the dealer. See the last page or the service tag on the system for the dealer’s address. Instructions for Use TORMAX 2101 T-1672 e... -
Page 15: System With Operating Mode Switch
If this does not reset the fault or if it re-occurs after a short time, you must arrange for the fault to be rectified by a skilled person from your TORMAX dealer. See the last page or the service tag on the system for the dealer’s address. Instructions for Use TORMAX 2101 T-1672 e... -
Page 16: Maintenance
The content of the maintenance work is specified by the manufacturer in an inspection list. System Test Book The test findings are recorded after the test in the system test book. The operator must keep it in a safe place. Instructions for Use TORMAX 2101 T-1672 e... -
Page 17: Appendix
• Emergency power • Wait for 15 min. till supply switched off. drive has cooled down. • Drive is overheated. • If no success, call TORMAX service. Instructions for Use TORMAX 2101 T-1672 e... -
Page 18: Check-List For Functional Checks
There are no ob- jects such as shelves, plant con- tainers and umbrella stands within a radius of 50 cm of the T1321_12 movement area. Instructions for Use TORMAX 2101 T-1672 e... - Page 19 - Declaration of incorporation by TORMAX | LANDERT Group AG - Risk evaluation for automatic sliding doors | T-1178 Person responsible for documents Name/address: Place, date: Signatory (CE authorized person): Signature: Instructions for Use TORMAX 2101 T-1672 e T-1063 e Declaration of Conformity...
- Page 20 the passion to drive doors TORMAX Swing Door Drives TORMAX Sliding Door Drives TORMAX Folding Door Drives TORMAX Revolving Door Drives installation repairs Producer Installation company ( , maintenance) TORMAX Unterweg 14 CH-8180 Bülach-Zürich Phone +41 58 500 5000 +41 58 500 5099 www.tormax.com info@tormax.com TORMAX is a division and a registered trademark of LANDERT Group AG...
