Installation On Site SWINGDOOR Smart Drive 1101 T-1132 e
1

Introduction

These instructions are addressed at qualified installation personnel and contain all
required information for the installation on site.
This document is applicable to automatic TORMAX doors of type SWINGDOOR Smart
Drive 1101.
Non-compliance endangers the safety of the installation personnel, the system operator
!
or the user.
Warning of electrical voltage.
Passages with text on grey background must be absolutely observed for reliable
performance of the system! Neglect can cause material damages.
This symbol marks optional components, which are not installed in all units.
These instructions are available in different languages. Please ask your TORMAX
dealer.
For installation and commissioning of this system, the following instructions and data
sheets are useful; get hold of these documents before beginning the assembly work!
• Operating instructions
• Wiring diagram lintel mounting
• Wiring diagram door leaf mounting
• Drilling template
• Dimensional drawings standard linkage lintel mounting
• Dimensional drawings standard linkage door leaf mounting T3-386-41
• Dimensional drawings sliding lever lintel mounting
• System test book International:
T-1134 e
T-1135 e
T-1154 e
T-1138
T3-386-40
T3-386-42
T-895 e
