Supplement to the Operating Instructions:
T-1165, T-1321
Area of application for drives:
TORMAX iMotion 2202, 2202.A, 2301, 2302, 2401 Sliding Door Drive
TORMAX 2201, Sliding Door Drive
TORMAX count+go
Contents
1
2
3
4
5
6
1

General Information

This supplement to the operating instructions is only complete when read in conjunction with operating instructions T-1165
or T-1321.
2

System Overview

3
6
5
3

Function of TORMAX count+go

The TORMAX count+go system counts and limits the traffic of people based on the door opening(s) in the entry and exit
direction. The operator defines the permitted number of persons in the room via mobile phone or PC. When this number is
reached, the current operating mode is switched to the operating mode EXIT. This ensures that people can leave the room
at any time, but access is blocked. The system provides visual and/or acoustic support to inform the users.
The operator can call up detailed information from TORMAX count+go via mobile phone at any time and adjust it if necessary.
In order to reliably prevent unauthorised access when the room is closed, the TORMAX count+go system cannot be accessed
in the operating mode OFF.
T-2035 e 19.1.2021
Subject to technical changes!
1
1
1
2
2
2
2
3
2
1
7
7.1
1
4
1
TORMAX count+go module
2
Load speaker
3
LED bar
Options:
4
Display
5
Barrier
6
Indicating sign
1
3
3
5
7
8
8
8
8
TORMAX | CH-8180 Bülach
www.tormax.com | info@tormax.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the T-1165 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Tormax Automatic T-1165

Summary of Contents for Tormax Automatic T-1165

  • Page 1: Table Of Contents

    5.2 Reset of the Passage Limitation Reset Individual Settings 7.2 Support General Information This supplement to the operating instructions is only complete when read in conjunction with operating instructions T-1165 or T-1321. System Overview TORMAX count+go module Load speaker LED bar...

  • Page 2: Applications

    Applications Managing the number of people in a room with a single en- Managing the number of people in a room with separated trance – exit door. entrance – exit doors. Operation 5.1 Activation of Passage Limitation Operating mode AUTOMATIC is active. The display and LED bar light green.

  • Page 3: Individual Settings

    Individual Settings 6.1 Connection to the User Interface Various settings can be made via smartphone or PC. • Connect your device to: WLAN: counter Password: tormaxcounter IMPORTANT: Your device must be connected via WLAN with the TORMAX count+go module. 6.2 First Login/Change Password •...
  • Page 4 Go to “Password” • Fill in your own username and your new password. Don’t forget to “Save” it. T-2035 e 19.1.2021 TORMAX | CH-8180 Bülach Subject to technical changes! www.tormax.com | info@tormax.com...

  • Page 5: Settings

    6.3 Settings The operator can make the following settings or alterations via the user interface: Browser: http://counter.tx/admin Set maximum number of persons allowed In this case max. 6 persons are allowed to enter and the actual number of persons is shown on the screen. In this case max.
  • Page 6 Enter text to be displayed • Change the texts that are shown on the green/red dis- play. The texts can be in different languages or lengths. • Line breaks can be made manually with the HTML com- mand <br>. • Check display/text with the "Preview" function/link. •...

  • Page 7: Show Display/Screen

    6.4 Show Display To show the TORMAX count+go display open a new tab and enter the URL: http://counter.tx This page shows the green/red display open directly the link “Display preview” on the admin site: Please wait Please enter Please wait Please enter 6 / 6 5 / 6...

  • Page 8: Set Actual Counter/Reset

    6.5 Set Actual Counter/Reset The operator can make the following settings or alterations via the user interface: Reset the counter to “0” or to any other number of persons • Set/correct the number of persons who have already passed the door. As soon as this number is set higher than the maximum number of per- sons allowed, the display changes to red.
