Summary of Contents for Tormax Automatic Smart Drive 1101
- Page 1 T-1132 e 3.03 Installation On Site for Automatic Swing Doors SWINGDOOR Smart Drive 1101...
-
Page 3: Table Of Contents
Fold-out page First edition: 9.02 provisional for 0-Series Update: 3.03 We print on environment-friendly paper bleached without chlorine. The enterprises Landert Motoren AG and Landert GmbH are certified according to ISO 9001. Installation On Site SWINGDOOR Smart Drive 1101 T-1132 e... -
Page 4: Introduction
• Dimensional drawings standard linkage lintel mounting T3-386-40 • Dimensional drawings standard linkage door leaf mounting T3-386-41 • Dimensional drawings sliding lever lintel mounting T3-386-42 • System test book International: T-895 e Installation On Site SWINGDOOR Smart Drive 1101 T-1132 e... -
Page 5: Safety
TORMAX operator and the following safety directions should be studied with great care and must be observed! In any case, please pay attention to the specially marked notes within this document (see chapter 1 for an explanation of symbols). Installation On Site SWINGDOOR Smart Drive 1101 T-1132 e... -
Page 6: Safeguarding Danger Points
– for the head 200 mm – for the body 500 mm Fingers are unlikely to penetrategaps ≤ 8 mm in powered pedestrian door installations. The safety measures may be used in combination. Installation On Site SWINGDOOR Smart Drive 1101 T-1132 e... -
Page 7: Organizational Measures
• Electric voltage/current: The operator is to be disconnected from electrical mains before any work is performed on electrical parts. Install cabling only after the installation is complete. Plug in the power plug only after all internal cables are connected. Installation On Site SWINGDOOR Smart Drive 1101 T-1132 e... -
Page 8: Basic Functions
An opening can only be initiated through the key switch. Operating Mode OFF An opening can be initiated by an activator, a key switch and also by “Push and Go” Operating Mode AUTO depending upon configuration. Installation On Site SWINGDOOR Smart Drive 1101 T-1132 e... - Page 9 The other feed back types can be chosen, but have no effect whatsoever. (See: Safety device Bodyguard). The control system Smart Drive 1101 provides a power supply of 24 VDC for sensors, Power Supply 24 VDC door lock and signalling.
-
Page 10: Installation
Installation Overview of mounting methods T1132/11 T1132/10 see 4.1 see 4.3 T1132/16 T1132/13 T1132/14 T1132/15 T1132/17 T1132/18 see 4.2 see 4.4 T1132/24 T1132/19 T1132/21 T1132/20 T1132/22 T1132/45 Installation On Site SWINGDOOR Smart Drive 1101 T-1132 e... -
Page 11: Lintel Mounting Standard Linkage
H) Interconnect bearing trestle and adjustment member T1132/25 Adjust adjustment member at right-angle to the lintel and tighten screws K) Interconnect connecting part and adjustment member L) Fasten covers M) Snap in side plates Installation On Site SWINGDOOR Smart Drive 1101 T-1132 e... -
Page 12: Door Leaf Mounting Standard Linkage
H) Interconnect bearing trestle and adjustment member T1132/26 Adjust adjustment member at right-angle to the lintel and tighten screws K) Interconnect connecting part and adjustment member L) Fasten covers M) Snap in side plates Installation On Site SWINGDOOR Smart Drive 1101 T-1132 e... -
Page 13: Sliding Lever U
K) Slide connecting part over cone and push up to the operator insert other end completely into bearing threstle, tighten cone Konus (hexagon-socket screw) and connecting part L) Fasten covers M) Snap in side plates Installation On Site SWINGDOOR Smart Drive 1101 T-1132 e... -
Page 14: Panic Fitting U
(hexagon-socket screw) and connecting part L) Fasten cover M) Snap in side plates Fasten rubber stop on the lintel, so that the connecting part will rest on it, when triggering the panic fitting. Installation On Site SWINGDOOR Smart Drive 1101 T-1132 e... -
Page 15: Mechanical Adjustments
The door should only be opened so far that the standard linkage cannot tip over and the sliding lever does not leave the rail. Door in open position at the end stop (internal max. 170 ° OPEN end-stop or door stopper). T1132/35 Installation On Site SWINGDOOR Smart Drive 1101 T-1132 e... -
Page 16: Electrical Connections
• Mount in accordance with contract order Facilities • Connect in accordance with connection diagram and the manufacturer’s specification • Adjust the detection field/sensitivity and action radius according to the requirements and the surroundings of the system. Installation On Site SWINGDOOR Smart Drive 1101 T-1132 e... - Page 17 *Swing area tech 24 V 24 V T1132/6e Legend: programmable +24 V 24 VDC (21 … 24 VDC) IN Input 24 VDC / 3 mA OUT Output NPN integrated protective diode Installation On Site SWINGDOOR Smart Drive 1101 T-1132 e...
- Page 18 Do not connect safety devices with monitoring and without monitoring in combination. Overall, the 24 V power supply may be loaded with max. 0.75 A, on overload the point LED goes out. Installation On Site SWINGDOOR Smart Drive 1101 T-1132 e...
-
Page 19: Commissioning Of The Automatic System
Attention: Changing the position of the linkage requires a new Teach-In. Programming Procedure (See table in section 7.4) Smart Drive 1101 possesses many useful features and parameters. These can be programmed through 2 keys and a digital display as follows: • Push simultuaneosly the yellow and the blue key programming mode is active. -
Page 20: Programming Examples
• Press the blue key once for confirmation of the choice Number 0 flashes (parameter) • Press the yellow key once Number 1 flashes (parameter) • Press the blue key once to execute the factory reset The point LED is lit Installation On Site SWINGDOOR Smart Drive 1101 T-1132 e... -
Page 22: 7.4.1 Programmable Functions
With the factory reset, all programming changes made are reset to the default values specified at the factory. The system must be re-commissioned in accordance with section 7.1, Commissioning With Teach-In General. Installation On Site SWINGDOOR Smart Drive 1101 T-1132 e... -
Page 23: Effect Of Homing In Speed And Angle For Homing In Speed Closing
[°] (function 8) All angular data is related Angle defined by function 5 to the drive shaft, not to door leaf angle homing in speed closing T1132/43e Installation On Site SWINGDOOR Smart Drive 1101 T-1132 e... -
Page 24: Low Energy Applications
Low Energy Applications With the operator Smart Drive 1101, door systems can be built that comply with the standards prEN12650 in Europe or ANSI A156.19 in the USA regarding low energy requirements. In order to comply with these standards, among other things, certain adjustments on the control system are necessary. -
Page 25: Trouble Shooting
– Start of damping too late or damping inadequate. – Differential pressure in the building – Operator defective (position sensor, motor) Irregular motion – Operator defective (position sensor, control system, motor) Installation On Site SWINGDOOR Smart Drive 1101 T-1132 e... -
Page 26: Check List
Informed the system operator of his obligations • Regular checks in accordance with the operating instructions • Annual service obligation through TORMAX dealer (in accordance with national regulations) Service contract offered Subject to technical changes Installation On Site SWINGDOOR Smart Drive 1101 T-1132 e... - Page 28 15 recouvrement 16 RS232 Schnittstelle 16 RS232 interface 16 RS232 interface 3.03 17 Kunststofflaschen für Kabel- 17 plastic nobs for cable ties 17 picots en plastique pour fixation câble SWINGDOOR Smart Drive 1101 binder 18 casing 18 habillage 18 Verschalung...
- Page 29 Your First Choice for Door Automation TORMAX SLIDEDOOR TORMAX SWINGDOOR TORMAX FOLDDOOR TORMAX REVOLVEDOOR TORMAX SLIDEGATE TORMAX BUILDING TECHNOLOGY Manufacurer: Consultation, sales, assembly, repair and service: TORMAX | CH-8180 Bülach-Zürich Phone +41 (0)1 863 51 11 +41 (0)1 861 14 74 Homepage www.tormax.com E-Mail...
