T-957 US801353
4-2-10
Installation and Service Manual
TDA SWING DOOR OPERATOR
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the TDA and is the answer not in the manual?

Questions and answers

Summary of Contents for Tormax Automatic TDA

  • Page 1 T-957 US801353 4-2-10 Installation and Service Manual TDA SWING DOOR OPERATOR...
  • Page 2 Contents Introduction Safety 3 - 4 5 - 8 Installation 200 series 9 - 13 Installation 100 series 110vAC Connection Teach In 15 - 16 Sensor wiring and input / output functions 17 - 22 Factory DirCom programming 23 - 29 Additional DirCom programming 30 - 35 Check List...
  • Page 3 Introduction These instructions are intended for AAADM Certified technicinas. Tormax strongly recommends all adjsstments be made in accordance with ANSI A156.10 and A 156.19 standards. These two symbols mark all passages that concern your safety: Symbols Used in these Instructions Warning of a health hazard of a general kind Warning of electric voltage/current Passages with text on grey background must be absolutely observed for reliable...
  • Page 4 Preventing General Hazards and Possible Damage to This Equipment • Verify that the power selection switch is set to the correct voltage before start-up. knockout that is close to the input power supply terminals. It should not be routed structure. It should not also be concealed behind walls, etc. parts of the operator, door, or system.
  • Page 5 3 Installation 200 series Out Swing...
  • Page 6 0” Reveal In Swing...
  • Page 7 0 “- 6” In Swing Arm (RH SHown)
  • Page 8 In Swing Parallel Arm (Speical Order) 11 - 13/16”...
  • Page 9 / or service issues for the customer. TDA (Over Head Concealed) Installation If the unit w as suppl ied with jambs they should be i nstalled at this time. If the unit was supplied without jambs, then the un it should be secured into the pr ovided locat ion us ing the appr opriate fasteners.
  • Page 10 Once installed the drive arm must be secured with the provided screw (M8 x 1.25 x 55 at head). Insert as shown (Pic. 2e), into the threaded bore in the TDA unit (Pic. 2f). The nished assembly can be seen in (Pic. 2g).
  • Page 11 DOOR INSTALLATION Install the door from the side op posite the normal swing path (breakout side) and at approximately 90 degrees to the TDA unit, place the door onto the bottom pivot (Pic 4a & 4b). Line up the drive arm re ceiver with the drive arm mounted to the TDA (Pic.
  • Page 12 (Pic 5a). TEACH IN AND FINAL ASSEMBLY The TDA overhead unit is now ready to be taught in. See Teach In instructions at the end of this docu ment. Install inspection covers (PN...
  • Page 13 In the event the dr ive arm needs to be removed proceed as follows. Lubricate and insert supplied bolt into drive arm. Hold drive arm wh ile tightening the bolt. Once the bolt bottoms against the TDA it will b egin to pull the drive arm out.
  • Page 14 Cable Routing cables. • Remove both cable straps. • Install emergency-off switch according to the contract order and route the mains connection via the emergency-off switch. Emergency-off switch Emergency-O Switch Mains connection TDA 230 V 50/60 Hz T957/1e 14 14...
  • Page 15 6 Teach - In TDA Single / Master “Teach-In” If required, the following basic adjustments of the door can be changed by the “Teach-In” function: SOFT KEY Opening speed Opening angle Do not hold Hold-open time (time delay) soft key down...
  • Page 16 Do not hold soft key down or programming will be deleted! PN: 408468 (Jumper Bee) TDA Slave “Teach-In” If required, the following basic adjustments of the door can be changed by the “Teach-In” function: Opening speed Opening angle Hold-open time (time delay) Slave “Teach-In”...
  • Page 17 E Module - Dry relay contact active when door is in programmed state. (NO or NC avaliable) .75 A max output from 24vdc output, use of 24vac trans is strongly recommended Factory Wiring for TDA 200 Single Ter minal C Terminal D...
  • Page 18 Inhibit Switch - Prevents door from operating also called break out switch. (NO input) .75 A max output from 24vdc output, use of 24vac trans is strongly recommended Factory Wiring for TDA 100 Single Terminal D Ter minal C Function Control Panel...
  • Page 19 BLACK/WHITE BROWN ORANGE GREY GREEN RED/WHITE WHITE...
  • Page 20 E Module - Dry relay contact active when door is in programmed state. (NO or NC avaliable) .75 A max output from 24vdc output, use of 24vac trans is strongly recommended Factory Wiring for TDA 200 Pair Master Slave Ter minal C...
  • Page 21 (NO or NC avaliable) Inhibit Switch - Prevents door from operating aslo called the break out switch. (NO input) .75 A max output from 24vdc output, use of 24vac trans is strongly recommended Factory Wiring for TDA 100 Pair Master Slave...
  • Page 22 BROWN ORANGE GRAY BLACK / WHITE WHITE RED/WHITE...
  • Page 23 Factory DirCom Programming Programming for TDA Single COMMERCIAL TDASICOM DIRCOM Codes In / Output P,20,4,W,20 Safety approach side P,20,5,W,21 Safety swing side P,20,6,W,6 Safety both sides P,30,20,W,0 Active level (active when closed) P,30,21,W,0 Active level (active when closed) P,30,9,W,0 Active level (active when closed)
  • Page 24 TDA OHC Single COMMERCIAL *** Press UP BUTTON for 4 beeps before programming *** TDAOHCLE DIRCOM Codes In / Output P,20,4,W,20 Safety approach side P,20,5,W,21 Safety swing side P,20,6,W,6 Safety both sides P,20,7,W,14 Reset after panic (OHC breakout) P,30,14,W,0 Active level (active when closed)
  • Page 25 TDA OHC LE Single COMMERCIAL *** Press UP BUTTON for 4 beeps before programming *** TDAOHCLE DIRCOM Codes In / Output P,20,4,W,20 Safety approach side P,20,5,W,21 Safety swing side P,20,6,W,6 Safety both sides P,20,7,W,14 Reset after panic (OHC breakout) P,30,14,W,0...
  • Page 26 Programming for TDA COMMERCIAL Pair DIRCOM Codes In / Output Master P,20,4,W,20 Safety approach side P,20,5,W,21 Safety swing side P,20,6,W,6 Safety both sides P,30,20,W,0 Active level (active when closed) P,30,21,W,0 Active level (active when closed) P,30,9,W,0 Active level (active when closed) P,40,0,W,29 Operating Mode –...
  • Page 27 Prog. for TDA OHC COMMERCIAL Pair *** Press BLUE UP BUTTON for 4 beeps before programming*** DIRCOM Codes In / Output Master P,20,4,W,20 Safety approach side P,20,5,W,21 Safety swing side P,20,6,W,6 Safety both sides P,30,20,W,0 Active level (active when closed)
  • Page 28 Prog. for TDA OHC COMMERCIAL Pair Low Energy *** Press BLUE UP BUTTON for 4 beeps before programming*** DIRCOM Codes In / Output Master P,20,4,W,20 Safety approach side P,20,5,W,21 Safety swing side P,20,6,W,6 Safety both sides P,30,20,W,0 Active level (active when closed)
  • Page 29 Programming for Double Egress REQUIRES 2 OFF/AUTO/HO SWITCHES MASTER DIRCOM Codes In / Output P,20,4,W,20 Safety approach side P,20,5,W,21 Safety swing side P,20,6,W,6 Safety both sides P,30,20,W,0 Active level (active when closed) P,30,21,W,0 Active level (active when closed) P,30,9,W,0 Active level (active when closed) P,40,0,W,37 Door opening or open E-module #1 relay A...
  • Page 30 Additional DirCom Programing planations 7.1 List of the DirCom Codes Units Explanations ms = Milliseconds SE = System units (abstract term) l/min = Revolutions per minute EF = edge of encoder pulse Applicable from software version A6299. Delay time to open: Motor-Driven Opening Motion Code Input...
  • Page 31 Homing-in speed: Code Input Minimum Standard Maximum Unit T,25,W,VALUE, l/min phase; high value = high speed. Tolerance of programmed open position: Code Input Minimum Standard Maximum Unit T,26,W,VALUE, = large admissible deviation. Reduced opening force: Code Input Minimum Standard Maximum Unit S,32,W,VALUE, –...
  • Page 32 = At the point of beginning of damping, the door is still wide open. Closing damping: Code Input Minimum Standard Maximum Unit T,40,W,VALUE, high damping or low speed. Motor supported closing action: Code Input Minimum Standard Maximum Unit T,90,W,VALUE, Value 0: Spring-operated closing; Value 1: Motor supported closing action from value T 88.
  • Page 33 internal reversing is not active in both directions; high value = large inactive range. Reversing is switched off if value equal 0. Internal reversing during closing: Code Input Minimum Standard Maximum Unit T,87,W,VALUE, nal reversing is not active in either direction; high value = large inactive range. Reversing is switched off if value equal 0.
  • Page 34 Operating mode return: Code Input Minimum Standard Maximum Unit T,110,W,VALUE, a mode change. By factory default, the original operating mode is not restored (value =0); if the value = 1 is programmed, the original operating mode is recalled. Operating mode selection: Code Input Minimum Standard...
  • Page 35 Reading the operator type: Code Input Minimum Standard Maximum Unit P ,1000,R, – Shows the programmed operator type: 8 stands for TDA, 9 stands for TDM. Door opening command through SERCOM: Code Input Minimum Standard Maximum Unit S,20, – Permits to issue an opening command from SERCOM.
  • Page 36 Check List Does the door / door panels swing freely w/o obstruction? Are all wires clear from moving parts? Are all adjustment bolts tight? Does the break out switch function on a 100 series application? Are there any error codes being displayed? Are all safety devices / sensors operating correctley? Has an ANSI A156.10 and / or ANSI A156.19 inspection been preformed? Are the Door# decal, Service decal, Daily Safety Check decal all...
  • Page 37 Your First Choice for Automatic Doors. TORMAX Sliding Doors TORMAX Swing Doors Sales, Installation and Service. Automatic and Manual Doors. Tormax Automatic 11803 Starcrest Drive San Antonio, TX 78247 888-685-3707 www.tormaxusa.com TORMAX is a Division and a registered trademark of Landert Motoren AG...
