Parts List - BodyCraft POWER ROW MB1631 Owner's Manual

NOTE:
QUALITY CONTROL PURPOSES. PLEASE PROCEED WITH ASSEMBLY.
(1) FRONT STABILIZER
(6) BUMPER
x 2pcs
NO. DESCRIPTION
15 M8 X 95mm HEX THREADED BOLT
17 M8 X 50mm INNER HEX SCREW
19 M6 X 10mm SET SCREW
23 M8 WASHER
24 M8 NYLON NUT
UPDATES:
#19 M6 x 10mm SET SCREW qty 4 are preinstalled in the #7 Seat Pad
#7 SEAT PAD & SEAT PAD SUPPORT PLATES are not pre-assembled as shown above.
The #7 SEAT PAD can be bolted onto the #5 SEAT PAD SUPPORT PLATES using the 4 pre-installed
M6 x 10mm Set Screws located in the #7 SEAT PAD. Please assemble at this time and tighten the bolts

Parts List 1

IF A PART IS MISSING, IT LIKELY HAS BEEN PRE-INSTALLED FOR
*Parts images are not to scale.
(3) MONORAIL
ASSEMBLY
(2) REAR STABILIZER
(9) OVAL END
CAP x 2pcs
QTY.
2
15
2
4
2
17
2
3
(4) FOOT PLATE
(7) SEAT PAD
& (5) SEAT PAD
SUPPORT PLATES
23
19
24
