X2 GYM STRENGTH TRAINING SYSTEM
INSTRUCTION MANUAL
QUESTION?
As a quality home gym supplier we are committed to your complete satisfaction. If you have
questions, or find missing or damaged parts, we will guarantee your complete satisfaction through
our authorized dealer service centers or our home office customer service department. Please call
your local dealer for assistance or BodyCraft at 800-990-5556 (9:00 AM - 5:00 PM). Our trained
technicians will provide immediate assistance to you, free of charge.
Bodycraft is a division of Recreation Supply Inc.
P.O. BOX 181
Sunbury, OH 43074
76600A

Advertisement

loading
Need help?

Need help?

Do you have a question about the X2 and is the answer not in the manual?

Questions and answers

Related Manuals for BodyCraft X2

Summary of Contents for BodyCraft X2

  • Page 1 Please call your local dealer for assistance or BodyCraft at 800-990-5556 (9:00 AM - 5:00 PM). Our trained technicians will provide immediate assistance to you, free of charge.

  • Page 2: Before You Begin

    7. Make certain all cables are seated within the pulleys before every use. 8. Exercise with care to avoid injury. 9. If unsure about the proper use of the BODYCRAFT X2 GYM strength training system call your local BODYCRAFT dealer or our customer...
  • Page 3 116A...
  • Page 4 EXPLODED VIEW...

  • Page 5: Table Of Contents

    PARTS CHART NO. DESCRIPTION QTY. BASE FRAME BASE STABILIZER REAR UPRIGHT FRONT UPRIGHT WEIGHT STACK BASE (Leg Press Side) WEIGHT STACK BASE (Low Row Side) WEIGHT STACK TOP (Leg Press Side) WEIGHT STACK TOP (Low Row Side) LOW ROW BASE TOP FRAME-bearing pre-installed LAT BAR HOLDER PRESS ARM SELERTOR...
  • Page 6 PARTS CHART NO. DESCRIPTION QTY. 45 X 75mm RECT. CAP 50mm SQ. CAP 45 X 75mm RECT. PLUG 50 X 75mm RECT. PLUG 50mm SQ. PLUG 45mm SQ. PLUG PLASTIC WASHER 30 X 60mm RECT. PLUG 25 X 50mm RECT. PLUG PLASTIC COVER 1/2"...
  • Page 7 PARTS CHART NO. DESCRIPTION QTY. 5/8" X 6-1/2" HEX BOLT 1/2" X 4" HEX BOLT 1/2" X 3" HEX BOLT 1/2" X 1-3/4" HEX BOLT 3/8" X 5-3/4" HEX BOLT 3/8" X 4-1/2" HEX BOLT 3/8" X 4" HEX BOLT 3/8"...

  • Page 8: Base Frame

    T E P 1 ASSE M BL E BASE FR AM E To ease the assembly process, do not tighten bolts until instructed. 1. Attach Base Stabilizers(2) to each end of Base Frame(1), using two 1/2" X 3" Hex Head Bolt(123) and two 1/2"...

  • Page 9: Lat Bar Holder

    T E P 2 ASSE M BL E T OP FR AM E 1. Attach Top Frame - bearing pre-installed(10) to Front and Rear Uprights(3, 4) using two 1/2" X 4" Hex Head Bolts(122) and two 1/2" Nylon Nuts(153). Attach Lat Bar Holder(11) to Top Frame - bearing pre-installed(10) using two 3/8"...
  • Page 10 T E P 3 ASSE M BL E SE AT S 1. Attach Front Seat Frame(18) to Front Upright(4) using two 3/8" X 3" Hex Head Bolts(128), four 3/8" Washers(147) and two 3/8" Nylon Nuts(154). Attach Front Seat Frame(18) to Base Frame(1) using two 3/8" X 4-1/2"...

  • Page 11: Press Arm

    T E P 4 ASSE M BL E BE NC H PR E SS AND L E G PR E SS 1. Attach Press Arm Selector(12) to Top Frame - bearing pre-installed(10) by aligning holes and inserting 1" Pivot Axle(33). Lock into place with pre-installed set screw. 2.
  • Page 12 PR E SS C ABL E Assemble cables and pulleys simultaneously. Attach loop end of Press Cable(109) to the bracket on Front Upright(4). Route cable over and around left (as if sitting on seat) side pulley mounted in Press Arm Selector(12), under and around pulley mounted in Front Upright(4), over and around right side pulley in Press Arm Selector(12) as shown Fig.
  • Page 13 L OW C ABL E Route Low Cable(110) under two Pulleys(82) on Low Row Base(9) as shown in Fig. 1, and 2, up over lower pulley in Adjustable Pulley Block(30) as shown in Fig. 3, down and ending under the pulley on Weight Stack Base(6) as shown in Fig. 4. Do not use this cable if you have purchased this option Hip Station.
  • Page 14 AB C R UNC H C ABL E Route the AB Crunch Cable(111) through(lower) slot and over pulley in Front Upright(4) as shown in Fig. 2, down and around the pulley mounted on rear of Front Upright(4), up and over lower pulley in Adjustable Pulley Block(30) as shown in Fig. 4, down and under two pulleys mounted on Base Frame(1) and attach cable end to bracket welded on Leg Extension Arm(20) as shown in Fig.
  • Page 15 T OP C ABL E Route threaded end of Top Cable(112) over pulley mounted to Top Frame(10) as shown in Fig. 1, through slot in Rear Upright(3), over pulley in Top Frame(10), under and around top pulley in Pulley Block(30), up and over pulley mounted on Weight Stack Top(7), under top pulley in Adjustable Pulley Block(30) as shown in Fig.3, up and over pulley mounted to Weight Stack Top(7) as shown in Fig.
  • Page 16 C ABL E AR M C ONNE C T T I NG C ABL E Hook Cable Arm Connecting Cable(113) on bracket welded to Cable Arm Assembly(27) then route up and over low pulley in Adjusterable Pulley Block(30) as shown in Fig. 2, then screw threaded cable end into Single Pulley Block(25).

  • Page 17: Pulley Guide Bracket

    C ABL E AR M C ABL E Slide Single Pulley Block(25) onto Pulley Guide Rod(16). Insert top end of Pulley Guide Rod(16) into top guide roe holder welded to Top Frame(10). Push Pulley Guide Rod(16) up into hole as far as possible, then slide bottom end of Pulley Guide Rod(16) into guide rod holder welded to Base Frame(1).
  • Page 18 L E G PR E SS C ABL E Screw threaded end(approx. half way) of Leg Press Cable(116) into receiver on Base Frame(1). Route cable up and over the lower pulley in Adjustable Pulley Block(30), then down and under the pulley on Weight Stack Base(4) as shown in Fig. 3. Then route cable under Weight Stack Base(5) as shown in Fig.

  • Page 19: Weight Stack Shroud

    T E P 5 ASSE M BL E W E I G H T ST AC K SH R OUDS AND POST E R PL AT E S 1. Attach Weight Stack Shrouds(32) to Weight Stack Bases(5 , 6) and Tops using 5/16" Washers(148) and 5/16"...

  • Page 20: Selector Pin

    Guide Rods (16). Enjoy many years of a Fit Lifestyle. Thank you for purchasing the Bodycraft X2 Home Gym. If You have any questions, please call your local BodyCraft dealer or call our customer service department at 800-990-5556...
