H-System – Isolated Barriers and Termination Boards

Configuration

4 Configuration
4.1

Configuration of the Isolated Barriers

Danger!
Explosion hazard from sparking when using operating elements
Using operating elements in a potentially explosive atmosphere can cause sparks that can
ignite the surrounding atmosphere.
Only use operating elements (e. g., switch, slider, button, etc.) in the absence of a potentially
explosive atmosphere.
Caution!
Fault in the plant
Changing the device data changes the device function.
Before entering new device data, make sure the plant is not endangered by changing
the device data.
The devices are configured using DIP switches.
Configuring the Isolated Barrier
Set the DIP switches on the device side as follows:
1. Remove the isolated barriers from the termination board as described in the "Dismounting"
section.
2. Set the DIP switches as described in the "Configuration" section of the datasheet.
3. Mount the device as described in the "Mounting" section.
Note!
See corresponding datasheets for further information.
