Establishing the HART Communication
Establish the HART communication via HART plug and HART multiplexer.
HART plug
Figure 2.15
HART multiplexer
Figure 2.16
Note!
See corresponding datasheets for further information.
Connection via control-side HART plug
HART multiplexer connection
