H-System – Isolated Barriers and Termination Boards
Mounting and Installation
Connect the Termination Board on the control side via the following connection options:
• Screw terminals
• Spring terminals
• Sub-D plug
• Control system-specific plug
Establishing the HART Communication
Establish the HART communication via HART plug and HART multiplexer on the control side.
Connecting Circuits
1. Connect the field circuit.
2. Connect the control circuit.
3. Connect the power supply.
4. Establish the HART communication.
Note!
See corresponding datasheets for further information.
