H-System – Isolated Barriers and Termination Boards
Technical Specifications
HiC Termination Board for 32 modules
Figure 7.5
HiD Termination Board for 8 Modules
253 mm (9.96")
163 mm (6.42")
Figure 7.6
48
150 mm (5.9")
