H-System – Isolated Barriers and Termination Boards
Product Specifications
Connecting the Control Side
The termination board on the control side can be connected via the following connection
options:
Screw terminals
Figure 2.11
Spring terminals
Figure 2.12
Sub-D plug
Figure 2.13
Control system-specific plug
Figure 2.14
14
Connection example: control-side screw terminals
Connection example: control-side spring terminals
Connection example: control-side Sub-D plugs
Connection example: control-side system plugs
