Keysight N9030A Signal Analyzer
Option C35
3.5 mm Input Connector Retrofit Kit
Notice: This document contains references to Agilent.
Please note that Agilent's Test and Measurement busi-
ness has become Keysight Technologies. For more in-
formation, go to www.keysight.com.
Installation Note
Part Number N9030-90047
Printed in USA August 2014
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Keysight Technologies N9030A
Summary of Contents for Keysight Technologies N9030A
- Page 1 Option C35 3.5 mm Input Connector Retrofit Kit Notice: This document contains references to Agilent. Please note that Agilent’s Test and Measurement busi- ness has become Keysight Technologies. For more in- formation, go to www.keysight.com. Installation Note Part Number N9030-90047...
- Page 2 The information contained in this document is subject to change without notice. Keysight Technologies makes no warranty of any kind with regard to this material, including but not limited to, the implied warranties of merchantability and fitness for a particular purpose. Keysight Technologies shall not be liable for errors contained herein or for incidental or consequential damages in connection with the furnishing, performance, or use of this material.
- Page 3 Introduction The Option C35 retrofit kit provides all the parts and instructions necessary to install the 3.5 mm input connector into the Agilent N9030A Option 526 (26.5 GHz spectrum analyzer). NOTE 1. The signal analyzer being upgraded with this option must have software version A.07.04 or newer.
- Page 4 Option C35, 3.5 mm Input Connector Retrofit Kit Contents Quantity Description Agilent Part Number Option Upgrade Entitlement Certificate Installation Note this note Screws, M3x0.5 8mm-LG (Crest Washer-Pan Head-TORX) 0515-0372 3.5 mm Input Connector Assembly N9020-60196 The input connector assembly is made up of: Input connector, 3.5 mm Bracket, Input Connector Nut, connector mounting...
-
Page 5: Installation Procedure
Installation Procedure Installation Procedure Remove the Instrument Outer Case, Front Panel Assembly, and Right Side Chassis (RF Bracket) CAUTION If the instrument is placed on its face during any of the following procedures, be sure to use a soft surface or soft cloth to avoid damage to the front panel, keys, or input connector. - Page 6 Installation Procedure over USB Installation Procedure over USB 1. Locate the Option Upgrade Entitlement Certificate from the kit. 2. Redeem the Option Upgrade Entitlement Certificate by following the instructions on the Certificate. 3. After redeeming your Option Upgrade Entitlement Certificate you will receive an email with an attached License File.
- Page 7 Installation Procedure over USB 7. The signal analyzer will automatically consume the License File. (This may take a few minutes) When the License File is consumed the Agilent License Manager will display a “Successful License Installation” message as shown in Figure Figure 2 Successful License Installation...
- Page 8 Adjustments, and Performance Verification Tests Adjustments, and Performance Verification Tests Calibration Software and specified test equipment is required to perform the adjustments and the performance verification testing. Information on how to obtain this software can be found at http://www.agilent.com/find/calibrationsoftware Adjustments Required Adjustments None anticipated, but dependent on possible performance test results.
