- Page 1 Keysight Technologies N9010A, N9020A, and N9030A Signal Analyzer Option FS2, Enhanced Fast Sweep Speed Installation Note...
- Page 2 The information contained in this document is subject to change without notice. Keysight Technologies makes no warranty of any kind with regard to this material, including but not limited to, the implied warranties of merchantability and fitness for a particular purpose.
- Page 3 Option FS2, Enhanced Fast Sweep Speed Upgrade Option FS2, Enhanced Fast Sweep Speed Upgrade Products Affected: N9010A, EXA Signal Analyzer N9020A, MXA Signal Analyzer N9030A, PXA Signal Analyzer Serial Numbers: Options Required: N90x0A-DP2, Digital Processor, 2 GB Capture Memory Applications Required:...
- Page 4 Option FS2, Enhanced Fast Sweep Speed Upgrade Installation Kit Parts List Quantity Description Keysight Part Number Entitlement Certificate 5964-5178 Entitlement Certificate Envelope 5967-7169 Installation Note This note Tools Required — Microsoft Windows based personal computer with internet access and USB port —...
- Page 5 Option FS2, Enhanced Fast Sweep Speed Upgrade Initial Instrument Functionality Check Power on the instrument and allow the instrument to boot up. Run an alignment and display the measurement screen. (The instrument will probably display a spectrum analyzer screen and you will see the instrument sweeping.) There should be no alignment failures.
- Page 6 Verify that the Product Number in step 2 is appropriate for the Option FS2 upgrade being installed: Option FS2 Upgrade Prod uct Number (Step 2) N9010AK-FS2 N9010A N9020AK-FS2 N9020A N9030AK-FS2 N9030A If the Product Number in step 2 is not appropriate for the Option FS2 upgrade, do not proceed with the installation.
-
Page 7: Update Instrument Software
Option FS2, Enhanced Fast Sweep Speed Upgrade Update Instrument Software Go to the following website and determine whether or not the analyzer has the latest instrument software already installed: http://www.keysight.com/find/xseries_software If the analyzer does not have the latest instrument software already installed, download and install the latest version. -
Page 8: Verify The License Installation
Option FS2, Enhanced Fast Sweep Speed Upgrade 7. The signal analyzer will automatically consume the License File. (This may take a few minutes) When the License File is consumed the Keysight License Manager will display a “Successful License Installation” message as shown in Figure 2. - Page 9 Option FS2, Enhanced Fast Sweep Speed Upgrade If you want to replace the FPGA image, under FPGA Load Preferences, click the Enhanced Sweep Speed selection, then click Load FPGA. An update FPGA status window will appear, and it will take approximately 13 minutes for the instrument to perform this task. It is very important the instrument power is not interrupted during this process! Notice under FPGA Load Preference, you can choose to be prompted with the window shown Figure...
- Page 10 Option FS2, Enhanced Fast Sweep Speed Upgrade Figure 3 FPGA Configuration Screen 6. Press System, Show, System, Next Page on the analyzer to display a list of installed options. Verify that N90x0A-FS2 Enhanced Fast Sweep Speed (where "x" is either 1, 2 or 3) appears. Verify Option FS2 Functionality 1.
- Page 11 Performance Tests Required — None End of installation. For assistance, contact your nearest Keysight Technologies Sales and Service Office. To find your local Keysight office access the following URL, or if in the United States, call the following telephone number: http://www.keysight.com/find/assist...
- Page 12 This information is subject to change without notice. © Keysight Technologies 2016 Edition 1, December 2016 N9040-90043 www.keysight.com...
