Javad TRIUMPH-1 Configuration Example page 4

Base and Rover Setup via Tracy
Base Configuration (TRIUMPH-1 with external UHF Modem)
Establishing Connection between receiver and Tracy
4. Power the HPT435. You can use the Battery kit 2 (p/n 99-587100-10).
5. Turn on the TRIUMPH-1 receiver
6. Start Tracy RTK in the Lite view.
7. Connect you TRIUMPH-1 and controller using Bluetooth.
• If you have once connected the receiver with Victor, Tracy will find it automatically;
• Otherwise click to the connection button to search bluetooth receiver.
4
Figure 1-2. Powering HPT435
Figure 1-3. Connection to the receiver
