UNMANAGED MODULES

Before installing, configure the iMcV-10G-Converter SFP+/SFP+ module/s
for desired features. The DIP Switch settings enable the end user to select
the speed/protocol, loopback modes and Loss Carry Forward (LCF). The
table below indicates the available features and settings for the iMcV-10G-
Converter SFP+/SFP+ module/s.
NOTE: You can also use iView
Switch
1 ON to Enable LCF from SFP+ 1 to SFP+ 2
2 ON to Enable LCF from SFP+ 2 to SFP+ 1
4,3 Combination of Settings
0,0 10G Ethernet
4,3
0,1 OC-192 SONET/SDH
1,0 0G Fiber Channel
1,1 ITU G.709 OTU-2
7 6
OFF OFF
OFF OFF
OFF ON
OFF ON
7,6,5
ON OFF
ON
OFF
ON ON
ON ON
8
NA
iMcV-10G Fiber Mode Converter
to choose specific 10G protocols.
2
Function
5 Combination of Settings
OFF No Loopbacks or Test Patterns
ON Enable Loopback SFP+ 1 (Line Side Optical)
OFF Enable Loopback SFP+ 2 (Line Side Optical)
ON Enable Loopback both SFP+ 1 and SFP+ 2
OFF na
ON
Send Test Pattern to SFP+ 1 (PRBS 2^31)
OFF Send Test Pattern to SFP+ 2 (PRBS (2^31)
ON
na
DIP Switch Settings
8
10.3125 Gb/S
9.9532 Gb/S
10.518 Gb/S
10.709 Gb/S
SFP+/SFP+
Default
OFF
OFF
Internal
Clock
Reference
Default 0,0
Default All
OFF
OFF
