7.1 Memory cards overview

You can use memory cards to archive data such as waypoints,
routes, and tracks.
Memory cards can be used to archive your data when the system
capacity is reached. You can then delete old data from your system,
creating capacity for new data. The archived data can be retrieved
at any time. You can also use memory cards to backup your data.
Note: Raymarine recommends that you backup your data to a
memory card on a regular basis.
76
7.2 Inserting a memory card or chart
card
1. Open the chart card door, located on the front right of the display.
2. Insert the card, as shown in the diagram below. For slot 1, the
card contacts should be facing DOWN. For slot 2, the card
contacts should be facing UP. Do NOT force the card. If the card
does not fit easily into the slot, check the orientation.
3. Gently press the card all the way in to the card slot, as shown in
the diagram below. The card is secure when an audible click is
heard.
4. To prevent the ingress of water and consequent damage, close
the chart card door.
e7 / e7D / e95 / e97 / e125 / e127 / c95 / c97 / c125 / c127
D12290-1
D12292-1
