- Page 1 Installation instructions English (en-US) Date: 06-2020 Document number: 87414-1 © 2020 Raymarine UK Limited...
- Page 3 Software updates Check the Raymarine website for the latest software releases for your product. www.raymarine.com/software Product documentation The latest versions of all English and translated documents are available to download in PDF format from the website: www.raymarine.com/manuals.
-
Page 5: Table Of Contents
Contents Chapter 1 Important information..................9 Disclaimers ..........................9 RF exposure ..........................9 Compliance Statement (Part 15.19) ..................9 FCC Interference Statement (Part 15.105 (b)) ................. 9 Innovation, Science and Economic Development Canada (ISED) ........10 Innovation, Sciences et Développement économique Canada (Français)......10 Japanese approvals ......................... - Page 6 6.6 Wi-Fi troubleshooting ....................... 60 6.7 Touchscreen troubleshooting..................63 6.8 Miscellaneous troubleshooting ..................64 Chapter 7 Technical support..................65 7.1 Raymarine product support and servicing ..............66 Viewing product information (LightHouse™ 3)...............67 7.2 Learning resources ......................68 Chapter 8 Technical specification................. 69...
- Page 7 8.1 Axiom+ technical specification ..................70 8.2 RealVision™ 3D sonar specification.................. 71 8.3 Internal GNSS (GPS / GLONASS) receiver specification ..........71 Chapter 9 Spares and accessories ................73 9.1 AXIOM accessories......................74 Axiom transducer adaptor cables..................74 Legacy MFD adaptor plates....................74 9.2 AXIOM spares........................
-
Page 9: Chapter 1 Important Information
Raymarine is not responsible for damages or injuries caused by your use or inability to use the product, by the interaction of the product with products manufactured by others, or by errors in chart data or information utilized by the product and supplied by third parties. -
Page 10: Innovation, Science And Economic Development Canada (Ised)
Contact information: Please contact your local authorized Raymarine dealer. MSIP Warning Statement for Radio Devices (Korea only) • 제작자 및 설치자는 해당 무선설비가 전파혼신 가능성이 있으므로 안전 인명과 관련된... -
Page 11: Declaration Of Conformity
In addition, our policy of continuous product improvement may change specifications without notice. As a result, Raymarine cannot accept liability for any differences between the product and this document. Please check the Raymarine website (www.raymarine.com) to ensure you have the most up-to-date version(s) of the documentation for your product. -
Page 13: Chapter 2 Document And Product Information
Chapter 2: Document and product information Chapter contents • 2.1 Product documentation on page 14 • 2.2 Applicable products on page 14 • 2.3 Compatible transducers for Axiom™+ RV Multifunction displays on page 16 • 2.4 Parts supplied - Axiom™ 7+ on page 19 •... -
Page 14: Product Documentation
For operation instructions for your product please refer to the LightHouse™ 3 MFD Operation instructions. The Basic (81369) and Advanced (81370) LightHouse™ 3 Operation Instructions can be downloaded from the Raymarine website: www.raymarine.com/manuals. Please check the website to ensure you have the latest documentation. 2.2 Applicable products This document is applicable to the following products: Axiom™+ Multifunction Displays... - Page 15 Product number Name Description E70634 Axiom™ 7+ 7” MFD Chartplotter. Axiom™ 7+ E70634–DISP 7” MFD Chartplotter (supplied with Rear mount kit only). E70635 Axiom™ 7+ RV 3D 7” MFD with built-in RealVision™ 3D sonar module. E70635–03 Axiom™ 7+ RV 3D (including RV–100 7”...
-
Page 16: Compatible Transducers For Axiom™+ Rv Multifunction Displays
• Non-CHIRP transducer can be connected using available adaptor cables. Refer to Chapter 9 Spares and accessories for a list of available adaptor cables. Refer to the Raymarine® website for compatible transducers: www.raymarine.com/transducers. Note: Chartplotter only variant Axiom™+ MFDs require a networked sonar module to enable sonar features. -
Page 17: Downvision™ Transducers
– RV-320S starboard transducer (A80474) • RV-400 RealVision™ 3D stainless steel 0° thru-hull all-in-one transducer (A80615) • RV-412P and RV-412S RealVision™ 3D stainless steel 12° thru-hull split-pair transducers (T70450) – RV-412P port transducer (A80616) – RV-412S starboard transducer (A80617) • RV-420P and RV-420S RealVision™ 3D stainless steel 20° thru-hull split-pair transducer (T70451) –... - Page 18 • CPT-S plastic transom transducer (E70342) • CPT-S plastic thru-hull 0° angled element (E70339) • CPT-S plastic thru-hull 12° angled element (A80448) • CPT-S plastic thru-hull 20° angled element (A80447) • CPT-S bronze thru-hull 0° angled element (A80446) • CPT-S bronze thru-hull 12° angled element (E70340) •...
-
Page 19: Parts Supplied - Axiom™ 7
2.4 Parts supplied - Axiom™ 7+ The parts listed are supplied with the following product numbers: E70634 and E70635. Unpack your product carefully to prevent damage or loss of parts. Check the box contents against the list below. Retain the packaging and documentation for future reference. MFD (supplied with Trunnion adaptor fitted) 2. -
Page 20: Parts Supplied - Axiom™ 9+ And Axiom™ 12
2. Rear mount brackets x 2 3. Suncover — Surface mount 4. Panel mount gasket for surface/flush mounting 5. M5x58 Threaded studs x 4 6. M5 Thumb nuts x 4 Documentation pack 8. DeviceNet to SeaTalkng ® adaptor cable 120 mm (4.7 in) 9. -
Page 21: Parts Supplied - Axiom™ 9+ (Disp) And Axiom™ 12+ (Disp)
2. Trunnion bracket 3. Trunnion knobs x 2 4. Suncover 5. Panel mount gasket for surface/flush mounting 6. Rear mounting brackets: a. supplied with 9” MFD b. supplied with 12” MFD Documentation pack 8. M5x58 Threaded studs x 4 9. M5 Thumb nuts x 4 10. - Page 22 2. Panel mount gasket for surface/flush mounting 3. Suncover 4. DeviceNet to SeaTalkng ® adaptor cable 120 mm (4.7 in) 5. M5x58 Threaded studs x 4 6. Rear mounting brackets: a. supplied with 9” MFD b. supplied with 12” MFD Documentation pack 8.
-
Page 23: Chapter 3 Installation
Chapter 3: Installation Chapter contents • 3.1 Selecting a location on page 24 • 3.2 Mounting options on page 30 • 3.3 Bracket (Trunnion) mounting on page 31 • 3.4 Axiom 7 flush and surface mounting on page 33 • 3.5 Surface or flush mounting using the Rear Mount Kit on page 35 Installation... -
Page 24: Selecting A Location
This will help to keep cable runs to a minimum. EMC installation guidelines Raymarine equipment and accessories conform to the appropriate Electromagnetic Compatibility (EMC) regulations, to minimize electromagnetic interference between equipment and minimize the effect such interference could have on the performance of your system Correct installation is required to ensure that EMC performance is not compromised. -
Page 25: Rf Interference
• Raymarine specified cables are used. • Cables are not cut or extended, unless doing so is detailed in the installation manual. - Page 26 This location provides optimal performance (above decks). In this location, performance may be less effective. This location is NOT recommended. Vessel construction The construction of your vessel can have an impact on performance. For example, the proximity of heavy structures such as a structural bulkhead, or the interior of larger vessels may result in a reduced signal.
-
Page 27: Touchscreen Location Requirements
Touchscreen location requirements Note: Touchscreen performance can be affected by the installation environment, specifically Touchscreen displays installed above decks, where it will be open to the elements may exhibit the following: • Hot Touchscreen temperature — If the display is mounted where it will be exposed to prolonged periods of direct sunlight, the touchscreen may become hot. -
Page 28: Product Dimensions
Product dimensions Axiom 7 trunnion mount dimensions 250.4 mm (9.86 in) 162.5 mm (6.4 in) 76.4 mm (3 in) • Straight connectors = 218 mm (8.58 in) • Right-angled connectors = 198 mm (7.79 in) Axiom 7 surface and flush mount dimensions Using adaptor bracket... - Page 29 Using Rear mount kit 201.1 mm (7.92 in) 133 mm (5.24 in) 8 mm (0.32 in) • Surface mounting = 19.05 mm (0.75 in) Maximum • Flush mounting = 27.05 mm (1.06 in) Maximum • Straight connectors = 218 mm (8.58 in) •...
-
Page 30: Mounting Options
Axiom™ 9 Axiom™ 12 265.03 mm (10.43 in) 314 mm (12.36 in) 187.81 (7.39 in) 226.72 mm (8.93 in) 76.71 mm (3.02 in) 76.2 mm (3 in) 65 mm (2.56 in) 65 mm (2.56 in) • Straight connectors = 178 mm (7.01 •... -
Page 31: Bracket (Trunnion) Mounting
Trunnion mount 2. Flush mount (Mounting surface and MFD screen a level)) 3. Surface mount (MFD screen protrudes slightly form mounting surface) 4. Front mount (using the Front Installation Kit accessory: 7”: A80498, 9”: A80500, 12”: A80502) Legacy MFD adaptor plates are also available to enable you to easily swap out older MFDs for new Axiom MFDs, please refer to Chapter 9 Spares and accessories for a list of available adaptors. - Page 32 Note: The illustration depicts an Axiom™ 7 being mounted on a plastic trunnion bracket. The trunnion bracket supplied with the Axiom™ 9 and Axiom™ 12 are made from metal and so look different than the trunnion shown. A metal trunnion bracket is also available for the Axiom™ 7 as an accessory;...
-
Page 33: Axiom 7 Flush And Surface Mounting
3.4 Axiom 7 flush and surface mounting Removing the trunnion adaptor Axiom™ 7 The trunnion adaptor supplied fitted to the Axiom™ 7 can be removed to enable the adaptor to be used as a clamp for surface and flush mount installations, the adaptor must also be removed before installation the unit using the Rear mount brackets or Front Installation kit. - Page 34 1. Using the Surface/Flush mounting template as a guide, cut the relevant cut out hole in the mounting surface, if you are Flush mounting the MFD, also follow the rebate information on the mounting template. 2. Screw the 4 x studs into the rear of the MFD. 3.
-
Page 35: Surface Or Flush Mounting Using The Rear Mount Kit
3.5 Surface or flush mounting using the Rear Mount Kit When suitable access is available behind the desired mounting surface then the MFD can be surface or flush mounted using the Rear Mount Kit. For Axiom™ 7 MFD, supplied with the trunnion adaptor fitted, first remove the Trunnion adaptor from the rear of the MFD. - Page 36 6. Secure the MFD in position by hand-tightening the thumb nuts onto the studs. Important: To prevent potential damage to the unit, do NOT overtighten the thumb nuts. Hand tighten only. 7. If required insert your MicroSD card into the MFD card reader located behind the rubber bung on the rear of the MFD.
-
Page 37: Chapter 4 Connections
Chapter 4: Connections Chapter contents • 4.1 Connections overview on page 38 • 4.2 Power connection on page 39 • 4.3 NMEA 2000 (SeaTalkng ®) connection on page 45 • 4.4 Transducer connection on page 45 • 4.5 Network connection on page 47 •... -
Page 38: Connections Overview
4.1 Connections overview Axiom™+ rear view Axiom™+ connectors Network connection — Connects to RayNet network or device. Refer to p.73 — Spares and Accessories for available cables. 2. Accessory connection — Connects to Remote Card Reader (RCR) accessory. 3. Power / NMEA 2000 connection — Connects to 12 V DC power supply / NMEA 2000 or SeaTalkng ®... -
Page 39: Power Connection
• The suitable fuse rating for the thermal breaker is dependent on the number of devices you are connecting. If in doubt consult an authorized Raymarine dealer. • Your product’s power cable may have an in-line fuse fitted, if not then you must add an in-line fuse / breaker to the positive wire of your product’s power connection. -
Page 40: Power Distribution
Power distribution Recommendations and best practice. • The product is supplied with a power cable, either as a separate item or a captive cable permanently attached to the product. Only use the power cable supplied with the product. Do NOT use a power cable designed for, or supplied with, a different product. Power connection •... - Page 41 Positive (+) bar Negative (-) bar Circuit breaker Waterproof fuse holder containing a suitably-rated inline fuse must be fitted. In-line fuse and thermal breaker ratings For suitable fuse rating, refer to: Important: Observe the recommended fuse / breaker ratings provided in the product’s documentation, however be aware that the suitable fuse / breaker rating is dependent on the number of devices being connected.
- Page 42 Waterproof fuse holder containing a suitably-rated inline fuse must be fitted. In-line fuse and thermal breaker ratings For suitable fuse rating, refer to: Product power cable. Drain wire connection point. Battery connection scenario A: Suitable for a vessel with a common RF ground point. In this scenario, if your product’s power cable is supplied with a separate drain wire then it should be connected to the vessel’s common ground point.
- Page 43 Important: To ensure power cables (including any extension) are of a sufficient gauge, ensure that there is a continuous minimum voltage of 10.8 V dc at the end of the cable where it enters the product’s power connector, even with a fully flat battery at 11 V dc. (Do not assume that a flat battery is at 0 V dc.
-
Page 44: Grounding - Optional Dedicated Drain Wire
Grounding — optional dedicated drain wire Frequencies emitted from equipment such as switch mode power supplies or MF/HF transmitters etc. can cause interference with your MFD’s touchscreen. If you experience issues with touchscreen performance, fitting an additional dedicated drain wire can resolve the issue. Note: The additional wire supplements the drain wire (shield) that is part of the product’s power cable and should ONLY be used when touchscreen interference is observed. -
Page 45: Nmea 2000 (Seatalkng ®) Connection
4.3 NMEA 2000 (SeaTalkng ®) connection The MFD can transmit and receive data from devices connected on a compliant CAN bus network that the MFD is also connected to. The MFD is connected to the backbone using the DeviceNet connector on the Power/NMEA 2000 cable. Power/NMEA 2000 cable connects to the rear of the MFD. -
Page 46: Realvision™ 3D Transducer Extension Cable
Note: Refer to 2.3 Compatible transducers for Axiom™+ RV Multifunction displays for more information on compatible transducers for your MFD variant. 2. Transducer extension cables are available. 3. MFDs that do not have a built-in sonar module can be connected to a transducer via an networked sonar module. -
Page 47: Network Connection
4.5 Network connection Your MFD can be directly connected to compatible products using the RayNet connections. Your MFD can also be connected to a SeaTalkhs ® network when using a suitable network switch. RayNet to RayNet cable — Connect one end of the RayNet cable to your MFD and the opposite end to a RayNet device or RayNet network switch. - Page 48 Device Supported media RCR-SDUSB (A80440)) 1x SD card (or MicroSD card when using an SD card adaptor) 1x USB (Type A connector) (e.g. for connection of an external USB hard drive or pen / flash drive) RCR-2 (A80218)) 2x MicroSD card For installation details for these devices, please refer to the instructions provided with your accessory.
-
Page 49: Chapter 5 Maintaining Your Display
Chapter 5: Maintaining your display Chapter contents • 5.1 Service and maintenance on page 50 • 5.2 Product cleaning on page 50 Maintaining your display... -
Page 50: Service And Maintenance
Warning: FCC Warning (Part 15.21) Changes or modifications to this equipment not expressly approved in writing by Raymarine Incorporated could violate compliance with FCC rules and void the user’s authority to operate the equipment. Caution: Sun covers •... -
Page 51: Cleaning The Display Case
4. Allow the screen to dry naturally. 5. If any smears remain, very gently wipe the screen with a fresh, clean, lint-free cloth. Cleaning the display case The display is a sealed unit and does not require regular cleaning. If it is necessary to clean the display, follow this basic procedure: 1. -
Page 53: Chapter 6 Troubleshooting
Chapter 6: Troubleshooting Chapter contents • 6.1 Troubleshooting on page 54 • 6.2 LED Diagnostics on page 54 • 6.3 Power up troubleshooting on page 55 • 6.4 GNSS (GPS) troubleshooting on page 56 • 6.5 Sonar troubleshooting on page 57 •... -
Page 54: Troubleshooting
If after referring to this section you are still having problems with your product, please refer to the Technical support section of this manual for useful links and Raymarine Product Support contact details. -
Page 55: Power Up Troubleshooting
In the unlikely event that the product’s software has become corrupted, try downloading and installing the latest software from the Raymarine website. 2. On display products, as a last resort, attempt to perform a ‘Power on Reset’. Be aware that this will delete all settings / presets and user data (such as waypoints and tracks), and revert the unit back to factory defaults. -
Page 56: Gnss (Gps) Troubleshooting
6.4 GNSS (GPS) troubleshooting Potential problems with the GNSS (GPS) receiver and possible causes and solutions are described here. Problem Possible causes Possible solutions “No Fix” GNSS status Geographic location or Check periodically to see if a fix is obtained icon is displayed. -
Page 57: Sonar Troubleshooting
External sonar module: • Check that the unit is correctly connected to the SeaTalkhs ™ / RayNet network multifunction display or Raymarine network switch. If a problem. crossover coupler or other coupler cable / adapter is used, check all connections ensuring connections are secure, clean and free from corrosion, replace if necessary. - Page 58 Possible causes Possible solutions Damaged cables Check the unit’s connector for broken or bent pins. 2. Check that the cable connector is fully inserted into the unit and that the locking collar is in the locked position. 3. Check the cable and connectors for signs of damage or corrosion, replace if necessary.
- Page 59 Possible causes Possible solutions Transducer location • Check that the transducer has been installed in accordance with the instructions provided with the transducer. • If a transom mount transducer is mounted too high on the transom it may be lifting out of the water, check that the transducer face is fully submerged when planing and turning.
-
Page 60: Wi-Fi Troubleshooting
6.6 Wi-Fi troubleshooting Before troubleshooting problems with your Wi-Fi connection, ensure that you have followed the Wi-Fi location requirements guidance provided in the relevant installation instructions and performed a power cycle/reboot of the devices you are experiencing problems with. Cannot find network Possible cause Possible solutions Wi-Fi not currently enabled on devices. - Page 61 Possible cause Possible solutions Interference caused by other devices that use Temporarily switch off each device in turn until the 2.4GHz frequency See list below of some you have identified the device causing the common devices that use the 2.4GHz frequency: interference, then remove or reposition the offending device(s).
- Page 62 Mobile application running slowly or not at all Possible cause Possible solutions Raymarine app not installed Install mobile app from relevant app store. Raymarine app version not compatible with MFD Ensure mobile app and MFD software are latest software available versions. Mobile apps not enabled on MFD Enable “Viewing only”...
-
Page 63: Touchscreen Troubleshooting
6.7 Touchscreen troubleshooting Problems with the touchscreen and their possible causes and solutions are described here. Problem Possible causes Possible solutions Touchscreen does not TouchLock is enabled. Swipe your finger from left to right across the operate as expected. Power button swipe area to de-activate the TouchLock. -
Page 64: Miscellaneous Troubleshooting
Check that the power source is of the correct • System crashes or voltage and sufficient current. other erratic behavior. Software mismatch Go to www.raymarine.com and click on on system (upgrade support for the latest software downloads. required). Corrupt data / other Perform a factory reset. -
Page 65: Chapter 7 Technical Support
Chapter 7: Technical support Chapter contents • 7.1 Raymarine product support and servicing on page 66 • 7.2 Learning resources on page 68 Technical support... -
Page 66: Raymarine Product Support And Servicing
You can obtain this product information using diagnostic pages of the connected MFD. Servicing and warranty Raymarine offers dedicated service departments for warranty, service, and repairs. Don’t forget to visit the Raymarine website to register your product for extended warranty benefits: http://www.raymarine.co.uk/display/?id=788. Region... -
Page 67: Viewing Product Information (Lighthouse™ 3)
• Tel: +45 437 164 64 Russia • E-Mail: info@mikstmarine.ru (Authorized Raymarine distributor) • Tel: +7 495 788 0508 Viewing product information (LightHouse™ 3) Use the Settings menu to view hardware and software information about your MFD, and connected products. -
Page 68: Learning Resources
7.2 Learning resources Raymarine has produced a range of learning resources to help you get the most out of your products. Video tutorials Raymarine official channel on YouTube: • YouTube LightHouse™ 3 tips and tricks: • Raymarine website Video Gallery: •... -
Page 69: Chapter 8 Technical Specification
Chapter 8: Technical specification Chapter contents • 8.1 Axiom+ technical specification on page 70 • 8.2 RealVision™ 3D sonar specification on page 71 • 8.3 Internal GNSS (GPS / GLONASS) receiver specification on page 71 Technical specification... -
Page 70: Axiom+ Technical Specification
8.1 Axiom+ technical specification Power Axiom™ 7+ Axiom™ 9+ Axiom™ 12+ Nominal supply 12 V dc voltage: Operating voltage 8 V dc to 16 V dc range: Fuse requirements: • Inline fuse = 7 Amp, or • Thermal breaker = 7 Amp Power consumption: •... -
Page 71: Realvision™ 3D Sonar Specification
Axiom™ 7+ Axiom™ 9+ Axiom™ 12+ Bluetooth: 1 x Bluetooth V4.0 LEN (Load Equivalency Number): Storage Axiom™ 7 Axiom™ 9 Axiom™ 12 Internal: 16 GB Solid State External microSD card: 1 x MicroSDXC card slot External (via • 1 x SD card slot RCR-SDUSB •... - Page 72 Operating frequency: 1574 MHz to 1605 MHz Signal Acquisition: Automatic Almanac Update: Automatic Geodetic Datum: WGS-84 (alternatives can be selected on the MFD) Refresh Rate: 10 Hz (10 times per second) Antenna: • Internal — Ceramic chip mounted near top of unit Position Accuracy: •...
-
Page 73: Chapter 9 Spares And Accessories
Chapter 9: Spares and accessories Chapter contents • 9.1 AXIOM accessories on page 74 • 9.2 AXIOM spares on page 75 • 9.3 RayNet to RayNet cables and connectors on page 76 • 9.4 SeaTalkng ® cables and accessories on page 78 Spares and accessories... -
Page 74: Axiom Accessories
9.1 AXIOM accessories Part number Name Details A80440 RCR-SDUSB External MicroSD and USB reader A80515 Right angled RV transducer adaptor cable A80498 7” Front installation kit Includes • Front mount adaptor • 2 x bezel pieces • 4 x self-tapping screws •... -
Page 75: Axiom Spares
Existing legacy MFD Adaptor part number New MFD Fixing holes C80 / E80 Classic A80564 Axiom 9” Existing C120 / E120 Classic A80529 Axiom 12” Existing e7 / e7D A80524 Axiom 7” Existing Note: The adaptor plates have been designed to utilize your legacy MFD’s existing cut out and fixing holes. -
Page 76: Raynet To Raynet Cables And Connectors
9.3 RayNet to RayNet cables and connectors Description Standard RayNet connection cable with a RayNet (female) socket on both ends. Right-angle RayNet connection cable with a straight RayNet (female) socket on one end, and a right-angle RayNet (female) socket on the other end. Suitable for connecting at 90° (right angle) to a device, for installations where space is limited. - Page 77 Description Adapter cable with a RayNet (female) socket on one end, and a waterproof (female) socket on the other end accepting the following cables with an RJ45 SeaTalkhs ® waterproof locking (male) plug: • A62245 (1.5 m). • A62246 (15 m). Adapter cable with a RayNet (female) socket on one end, and a waterproof (female) RJ45 socket on the other end, along with a locking gland for a watertight fit.
-
Page 78: Seatalkng ® Cables And Accessories
9.4 SeaTalkng ® cables and accessories SeaTalkng ® cables and accessories for use with compatible products. Part Number Description Details Includes: T70134 Starter kit • 1 x 5 Way connector (A06064) • 2 x Backbone terminator (A06031) • 1 x 3 m (9.8 ft) spur cable (A06040) •... - Page 79 Part Number Description Details A06047 SeaTalk (3 pin) to SeaTalkng ® adaptor cable 0.4 m (1.3 ft) A22164 SeaTalk to SeaTalkng ® spur cable 1 m (3.3 ft) A06048 SeaTalk2 (5 pin) to SeaTalkng ® adaptor cable 0.4 m (1.3 ft) A06045 SeaTalkng ®...
- Page 81 Index EMC, Electromagnetic Compatibility Ethernet connection ..........47 External storage connection........47 Accessories ............. 74 Network adapter cables ........76 Network cables............ 76 Factory reset ............55 RayNet cables............76 Fuse rating...............39 SeaTalkng cables ..........78 Accessory connection ..........47 Adaptor plates ............74 Axiom™+ MFDs............14 Installation Best practice ............
- Page 82 Battery connection..........41 Distribution ............40 Warranty ..............66 Distribution panel..........40 WEEE Directive............11 Grounding............43 Wireless Sharing a breaker ..........40 Interference ............27 Power cable extension ..........42 Power connection ...........39 Power troubleshooting ..........55 Product information ..........67 Product recycling (WEEE) ......... 11 Product support............66 Product variants............14 Radio Frequency (RF) interference......25...
- Page 84 Raymarine Marine House, Cartwright Drive, Fareham, Hampshire. PO15 5RJ. United Kingdom. Tel: +44 (0)1329 246 700 www.raymarine.com a brand by...
