Perlesmith PSLTK2 Manual page 3

STEP1 Check the VESA pattern of your TV
The small and medium assembly option is for smaller TVs where the full assembly may
stick out on either side. The mount is shipped in the medium assembly option.
STEP2 Install TV bracket
Check TV screws
Please select the proper screw length for your TV by hand tightening to check your plat pance thread depth.
Max 600mm（23 5/8 in）
75 mm ≈ 2 7/8 in
100 mm ≈ 4 in
200 mm ≈ 7 7/8 in
300 mm ≈ 11 3/4 in
400 mm ≈ 15 3/4 in
600 mm ≈ 23 5/8 in
2
