DEMO MANUAL DC2429A

parts list

ITEM QTY REFERENCE
Required Circuit Components
1 16 C1, C3-C7, C9-C11, C19-C21,
C23-C25, C35
2 0 C2, C8, C18, C22
3 0 C12
4 4 C13, C14, C16, C17
5 1 C15
6 7 C26-C28, C32-C34, C37
7 3 C29, C30, C31
8 1 C36
9 4 D1, D2, D3, D4
10 9 E1-E9
11 4 JP1-JP4
12 1 JP5
13 1 J1
14 8 J2-J5, J8-J11
15 0 J6
16 1 J7
17 1 L1
18 3 L2-L4
19 2 R1, R11
20 4 R2, R3, R8, R9
21 2 R4, R10
22 4 R6, R13, R25, R26
23 1 R7
24 1 R14
25 0 R15-R18, R20, R21
26 1 R19
27 1 R22
28 1 R23
29 1 R27
30 1 R28
31 1 R29
32 1 R30
33 1 R31
34 1 R32
35 1 R33
4
Arrow.com. Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from Downloaded from
PART DESCRIPTION
CAP ., X7R, 4.7µF, 50V, 10%, 1206
CAP ., ALUM. ELECT., 10µF, 50V, 10%, CE-BSS
CAP ., 0603
CAP ., X7R, 1µF, 16V, 10%, 0603
CAP ., X7R, 0.01µF, 16V, 10%, 0603
CAP ., X7R, 0.1µF, 16V, 10%, 0603
CAP ., X7R, 0.47µF, 50V, 10%, 0805
CAP ., ALUM. ELECT., 22µF, 50V, 10%, CE-BSS
LED, GREEN, LED-ROHM-SML-01
TURRET, 0.064"
CONN., HEADER, 1x3, 2mm
CONN., HEADER, 2X7, 2mm
CONN., PWR JACK, CON-CUI-PJ002AH
JACK, BANANA
CONN., SMA 50-OHM EDGE-LAUNCH
CONN., SMA 50-OHM EDGE-LAUNCH, MALE
IND, FERRITE BEAD, L-0603LS-1608
IND, FERRITE BEAD, L-0603LS-1608
RES., CHIP , 280, 1/10W 1%, 0603
RES., CHIP , 0.05, 1/4W 5%, 0805
RES., CHIP , 453k, 1/8W 1%, 0805
RES., CHIP , 49.9k, 1/8W 1%, 0805
RES., CHIP , 8.25k, 1/8W 1%, 0805
RES., CHIP , 33.2k, 1/8W 1%, 0805
RES., 0603
RES., CHIP , 100, 1/10W 1%, 0603
RES., CHIP , 698k, 1/8W 1%, 0805
RES., CHIP , 619, 1/10W 1%, 0603
RES., CHIP , 1.21k, 1/10W 1%, 0603
RES., CHIP , 24.9k, 1/4W 1%, 1206
RES., CHIP , 33.2k, 1/4W 1%, 1206
RES., CHIP , 49.9k, 1/4W 1%, 1206
RES., CHIP , 80.6k, 1/4W 1%, 1206
RES., CHIP , 100k, 1/4W 1%, 1206
RES., CHIP , 121k, 1/4W 1%, 1206
MANUFACTURER/PART NUMBER
MURATA, GRM31CR71H475KA12L
SUN ELECT., 50CE10BSS
OPT
MURATA, GRM188R71C105KA12D
MURATA, GRM188R71C103KA01D
MURATA, GRM188R71C104KA01D
MURATA, GRM21BR71H474KA88L
SUN ELECT., 50CE22BSS
ROHM, SML-012P8TT86
MILL-MAX, 2308-2-00-80-00-00-07-0
WURTH ELEKTRONIK, 62000311121
SULLINS, NRPN072PAEN-RC
CUI INC., PJ-002AH
KEYSTONE, 575-4
OPT
EF JOHNSON, 142-0801-801
TAIYO YUDEN, FBMH1608HL121-T
TAIYO YUDEN, FBMH1608HL331-T
VISHAY, CRCW0603280RFKEA
PANASONIC, ERJ-L06KJ50MV
VISHAY, CRCW0805453KFKEA
VISHAY, CRCW080549K9FKEA
VISHAY, CRCW08058K25FKEA
VISHAY, CRCW080533K2FKEA
OPT
VISHAY, CRCW0603100RFKEA
VISHAY, CRCW0805698KFKEA
VISHAY, CRCW0603619RFKEA
VISHAY, CRCW06031K21FKEA
VISHAY, CRCW120624K9FKEA
VISHAY, CRCW120633K2FKEA
VISHAY, CRCW120649K9FKEA
VISHAY, CRCW120680K6FKEA
VISHAY, CRCW1206100KFKEA
VISHAY, CRCW1206121KFKEA
dc2429af
