typical Dc2429a reQuirements anD characteristics
Table 1. DC2429A Assembly Options
PARAMETER
6V to 20V Power Supply
3.3V, 800mA
5V, 200mA
Variable, 200mA
Variable, 200mA
Output Voltage Selection
REF+
REF–
3.3V Jumper
3.3V_REF Jumper
5V Jumper
Variable Jumper
Arrow.com. Arrow.com. Arrow.com.
Downloaded from Downloaded from Downloaded from
INPUT OR OUTPUT

PHYSICAL LOCATION

Input J1 Wall Wart Connector or
J2 and J3 BNC Banana Jacks
Output J4 and J5 BNC Banana Jacks Load shares 4 LT3042 to achieve 800mA output current capability.
Output J8 and J9 BNC Banana Jacks
Output J10 and J11 BNC Banana
Input
Output
Output J6 (not installed)
Input
Input
Input
Input
DEMO MANUAL DC2429A
6V to 20V input power supply voltage must be 350mV greater than
the higher of 6V or the desired variable, 200mA output voltage.
Up to 1.4A current consumption.
LEDs D1-D4 illuminate when power supplied.
To avoid coupling between input and output supplies it is best to
use shielded power supply cables.
See schematic.
JP5 selects output voltage
Jacks
6V to 20V input power supply voltage must be 350mV greater than
the higher of 6V or the desired variable, 200mA output voltage.
JP5 Selects variable, 200mA supply output voltage
(Options: 2.5V, 3.3V, 5V, 8V, 10V, 12V, 15V).
J7 Male SMA connector.
100MHz, 3.3V CMOS thru 100Ω series, AC coupled.
Default: not installed. Install if differential reference is desired.
JP1 Default: set to ON.
Connected to LT3042 EN/UV pin (U1, U4, U5 and U6).
JP2 Default: set to ON.
Connected to LT3042 EN/UV pin (U2).
JP3 Default: set to ON.
Connected to LT3042 EN/UV pin (U3).
JP4 Default: set to ON.
Connected to LT3042 EN/UV pin (U8).
