parts list
ITEM
QTY
REFERENCE
36
1
R34
37
7
U1-U6, U8
38
1
U7
39
5
SHUNT ON JP1-JP5 AS SHOWN ON
ASSY DWG
40
4
MH1-MH4
Arrow.com.
Arrow.com.
Arrow.com.
Arrow.com.
Arrow.com.
Downloaded from
Downloaded from
Downloaded from
Downloaded from
Downloaded from
DEMO MANUAL DC2429A
PART DESCRIPTION
RES., CHIP , 150k, 1/4W 1%, 1206
I.C., DFN10DD-3X3
I.C., 100MHz OSCILLATOR, OSC-VCXO/CVS575S
SHUNT, 2mm
STANDOFF , NYLON, 0.5, 1/2"
MANUFACTURER/PART NUMBER
VISHAY, CRCW1206150KFKEA
LINEAR TECH., LT3042EDD
CRYSTEK, CCHD-575-25-100.000
WURTH ELEKTRONIK, 60800213421
WURTH ELEKTRONIK, 702935000
dc2429af
