Ergotron StyleView Hot Swap Power system User Manual page 9

CARTS WITH DUAL T-SLOTS ON REAR OF CART:
SV31
NEO-FLEX WIDEVIEW
WORKFIT C
1
Follow instructions provided with the
mounting brackets.
2
7.5"
(190 mm)
3
Follow instructions on page 11.
888-83-071-G-00 rev. B • 11/13
Double T-slot bracket -
ordered separately
(For center mounting
on back of cart)
32"
(813 mm)
11
Single T-slot bracket -
see page 10
(For off-center mounting
on either rear corner of cart)
10
9 of 13
