- Page 1 MANUAL ENGLISH Sunpanel iPW-150 Rigging Bar V1 Ordercode: 33201 Highlite International B.V. – Vestastraat 2 – 6468 EX – Kerkrade – the Netherlands...
-
Page 2: Table Of Contents
Sunpanel iPW-150 Rigging Bar Table of contents Warning ....................................2 Unpacking Instructions ..............................2 Safety Instructions ................................. 2 Operating Determinations ............................3 Return Procedure ................................4 Claims ....................................4 Description of the device ..............................5 Features ..................................5 Major Components ................................5 Installation ................................... -
Page 3: Warning
Sunpanel iPW-150 Rigging Bar Warning Unpacking Instructions Immediately upon receiving this product, carefully unpack the carton and check the contents to ensure that all parts are present, and have been received in good condition. Notify the dealer immediately and retain packing material for inspection if any parts appear damaged from shipping or the carton itself shows signs of mishandling. -
Page 4: Operating Determinations
Sunpanel iPW-150 Rigging Bar IMPORTANT: The manufacturer will not accept liability for any resulting damages caused by the non-observance of this manual or any unauthorized modification to the device. Never remove warning or informative labels from the device. Use the device only for the intended purpose. -
Page 5: Return Procedure
Sunpanel iPW-150 Rigging Bar Return Procedure Returned merchandise must be sent prepaid and in the original packing, call tags will not be issued. Package must be clearly labeled with a Return Authorization Number (RMA number). Products returned without an RMA number will be refused. Highlite will not accept the returned goods or any responsibility. Call Highlite 0031-455667723 or mail aftersales@highlite.nl and request an RMA prior to shipping the fixture. -
Page 6: Description Of The Device
Sunpanel iPW-150 Rigging Bar Description of the device Features Solid and reliable construction Easy to assemble 3 x hanging ring 2 x L-style locking bolt 2 x Stand stud adapter Fig. 01 Note: 01) Sunpanels can be assembled horizontally and then their number is unlimited . 02) When assembled vertically, the number of the fixtures cannot exceed 6. -
Page 7: Installation
Sunpanel iPW-150 Rigging Bar Installation 01) Check whether the Stand Stud Adapter is extended out of the bottom. Normally, the factory setting is as shown in fig. 03. Fig. 03 Fig. 04 02) If the Stand Stud Adapter is set as in fig. 04, please press it down and turn clockwise by 90 degrees to keep the screw head line with the slot in the bottom. - Page 8 Sunpanel iPW-150 Rigging Bar 06) Place the bottom of the Rigging Bar facing to the safety anchor points of the LED Sunpanel. Fig. 09 07) Insert the safety anchor points of LED Sunpanel into the Safety anchor slot of the Rigging Bar. Fig.
-
Page 9: Operation
Sunpanel iPW-150 Rigging Bar Operation The hanging ring of the rigging bar is designed to accept a variety of mounting hooks, clamps , etc. for hanging applications . Fig. 13 Note: 01) Sunpanels can be assembled horizontally and their number is then unlimited . 02) When assembled vertically, the number of the fixtures cannot exceed 6. -
Page 10: Maintenance
Sunpanel iPW-150 Rigging Bar Maintenance The iPW-150 Rigging Bar requires almost no maintenance. However, you should keep the unit clean. The components are finished in a black powder coat finish. In normal conditions, this finish is supposed to protect the main components against corrosion. Contact with water or corrosive chemicals can weaken elements of the unit. - Page 11 Sunpanel iPW-150 Rigging Bar Notes Ordercode: 33201...
