Steelcase Answer Manual page 3

NOTE: The glass screen must be
no wider than the Fence segment,
and cannot span over any junction.
1
To remove
4x
NOTE: Power Infeeds need to be
removed in order to release Cover clips.
Glass Width
24", 30", 36", 42", & 48"
60" & 72"
NOTE: If there are no clevis holes in
the horizontal bar, go to page 10.
Cover
Flat head thread forming
(blue screw supplied)
Number of Clevises
2 (each end)
3 (each end and center)
TIP: A straight blade screwdriver or a putty
knife can be used to move installed covers
laterally if needed for adjacent cover installation.
1/4-20 x 3/4"
hex cap screw
8x
Clevis
2a
NOTE: For center clevis installation,
go to page 10.
2b
2x
Page 3 of 10
137658 Rev B
